Sliding Table Scoring Saw
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Type:
Table Panel Saw
Use:
Woodworking
Style:
Horizontal
Payment & Shipping
Payment Methods:
Port of Shipment:
QINGDAO PORT
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Type
Table Panel Saw
Use
Woodworking
Style
Horizontal
Place of Origin
Shandong, China
Brand Name
GODN
Model Number
MJ6132TZ/MJ6138TZ
Specifications
sliding table scoring saw:1)Saw blade diameter:80mm
2)Tilting saw blade 0-45
Sliding table scoring saw:
Parameter:
MODEL |
MJ6132TZ |
MJ6138TZ |
Dimensions sliding table |
3200×360mm |
3800×360mm |
Cross cut capacity |
3200mm |
3800mm |
Width of cut between saw blade and rip fence |
1250mm |
1250mm |
Saw blade |
Φ 300mm(Φ250-Φ300) |
Φ 300mm(Φ250-Φ300) |
Height of cut |
80mm |
80mm |
Height of cut with saw blade Φ300mm at 45° |
55mm |
55mm |
Speed of main saw blade |
4000/6000rpm |
4000/6000rpm |
Spindle diameter |
30mm |
30mm |
Tiling saw blade |
0-45° |
0-45° |
Main motor |
4kw |
4kw |
Scoring saw blade |
120mm |
120mm |
Speed of scoring saw blade |
8000rpm |
8000rpm |
Spindle of scoring saw |
20mm |
20mm |
Motor |
0.75kw |
0.75kw |
Net Weight |
640kg |
690kg |
Gross Weight |
790kg |
830kg |
Overall dimensions |
3250x3250×900m |
3800x3250×900m |
Thanks for your attention.
If you have any questions please contact with us without any hesitation.
