LGSJ-1400 EPS Batch-type Foaming Granulator

FOB Price

US$ 30,000 - 50,000 / Set

1 Set(Min. Order)

Port Qingdao
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Type	Granulating Production Line
Capacity	80-120kg/h	Place of Origin	Shandong, China
Brand Name	Liangong	Model Number	LGPSJ-1400
Material	Other, EPS	Screw Design	Single
Voltage	380KV	Power	2.3kw
Weight	0.4t	Certification	ce
Warranty	1 year	After-sales Service Provided	Engineers available to service machinery overseas

Product Description

EPS batch-type foaming machine

Use and characteristic :

EPS batch -type foaming granulator is nainly use to be making the PS foaming granules .Produces the pellet widely uses in keeping warm fills,professions and so on toy,This machine production foaming pellet may control in the 0.8-2.2mm diameter and 12-60 kg/m3 density ,by foaming time .pressure.temperature ,control its foaming multiple and diameter control.

2 The machine uses the PLC programmable controller and the touchscreen ,the automatic feeding materical automatic tempetature control .pressurize and feeding quantificationally,it realizes the completely automatic production .

3 The high quality enclosed constant pressure foaming ,the rhermao efficiency is high ,it than continuous foaming machine to save over 50%of steam.

4 Uses the high quality enclosed imported air control valve ,cause its temperature control in ±1%,EPS granules achieves consistently , the moisture content is extremely low .

Technical parameters:

Model no. parameters			LGPSJ-460	LGPSJ-800	LGPSJ-1400
Cylinder size	Cylinder inside diameter	mm	460	800	1400
Cylinder size	Cylinder height	mm	700	1200	1700
Cylinder Volume		m³	0.1	0.6	2.3
Foaming density		Kg/m³	12-60	12-60	12-60
Production efficiency		Kg/h	40-60	80-120	300-500
Stean pressure		Mpa	0.4-0.8	0.4-0.8	0.4-0.8
Compressed air pressure		Mpa	0.6-0.8	0.6-0.8	0.6-0.8
Steam inlet		mm	25	32	40
Compressed air inlet		mm	32	32	32
Pollution discharge outlet		mm	50	50	80
Exhaust outlet		mm	80	80	100
Dimensions		mm	2100×700×2400	1800×1300×3000	1900×2200×4600

Matched boiler no.		T	0.2	0.3	0.4

thank you for your consulatiom ,if you are interested in our products ,please contact with me!
