24*15MM 8ohm 1W Multimedia Speaker Drivers, Oem Raw Speaker Horn

24*15MM 8ohm 1W Multimedia Speaker Drivers, Oem Raw Speaker Horn thumbnail-1
24*15MM 8ohm 1W Multimedia Speaker Drivers, Oem Raw Speaker Horn photo-1
US$ 0.25 - 0.35 MOQ: 5000 Pieces
Key Specifications
Get Latest Price
Brand Name:
Hysun or OEM
Model Number:
2415N0401-1
Type:
Active
Contact Supplier Request Quote Chat Now
Shenzhen Hengxintai Electronics Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name Hysun or OEM
Model Number 2415N0401-1
Type Active
Use Home Theatre, Portable Audio Player, Mobile Phone, Karaoke Player, Computer, Stage
Channels 2 (2.0)
Special Feature Wireless, Portable, Mini
Place of Origin China

Specifications

24*15MM 8ohm 1W multimedia Speaker drivers, oem raw speaker horn
Size: 24*15mm
Specifcation: 8ohm 1W

24*15MM 8ohm 1W multimedia Speaker drivers, oem raw speaker drivers

“S2415N0401-1"  D2415   H4.0  8 OHM  RaSH   RoHS   PBT”



1. SCOPE

This specification covers our product of dynamic   speaker unit for mobile telephone use.

24*15MM 8ohm 1W multimedia Speaker drivers, oem raw speaker horn



2.GENERAL REQUIREMENTS

      2.1 OPERATING TEMPERATURE RANGE: -20°C~+60°C

      2.2 STORAGE TEMPERATURE: -30°C~+70°C

      2.3 STANDARD TEST CONDITIONS:

            Temperature:            17~25°C

            Relative Humidity:       45%~80%(RH)

            Air Pressure:           860~1060 h Pa

      2.4 JUDGEMENT CONDITIONS:

           Temperature:             20~30°C

           Relative Humidity:       50%~80%(RH)

           Air Pressure:            860~1060 h Pa



3. SPEAKER MODE

3.1 SOUND PRESSURE LEVEL

99±3dBSPL @0.5,0.8,1.0,1.5KHz in average  (0dB SPL=20μPa)

Measuring condition: 0.1W (Sine wave) 0.1m measured with baffler shown in Fig.1.

3.2 IMPEDANCE: 8±15%ohm(@2KHz 1V) without baffler.

3.3 MEASURING DIAGRAM: Shown in Fig.1.

3.4 TYPICAL FREQUENCY RESPONSE CURVE: Shown in Fig.2.

3.5RATED POWER:1W.  MAX POWER: 1.2W

3.6 RESONANCE FREQUENCY (F0):800±20%Hz @ 1V. (Without Baffler)

3.7 DISTORTION: less than 10% at 2KHz, 0.1w,0.1m

3.8 BUZZ RATTLE: Must be normal at sine wave 1W (2.83V) (100Hz~2000Hz)
