Foshan Tonon Plycarbonate Sheet Manufacture Bayer Policarbonato Hollow Panel Made in China (TN1681)
- Guangzhou / Shenzhen / Foshan
- T/T Credit Card
You May Like
-
Foshan Tonon Polcyarboante Sheet Manufacture Blue pc Hollow Panel Made in China (TN)
-
Foshan Tonon Polycarbonate Panel Manufacture Semi Transparent Plastic Sheets in China (TN1550)
-
Foshan Tonon Manufacturer Flexible Transparent Plastic Sheet Cutom-made in China (TN1582)
-
Foshan Tonon Polycarbonate Sheet Manufacturer Clear Plastic Roofing Panels Made in China (TN1614)
-
Foshan Tonon Polycarbonate Panel Manufacture Polycarbonate Roofing Sheet Made in China (TN1663)
-
Foshan Tonon Polycarbonate Panel Manufacturer Clear Roof Sheet Made in China (TN1664)
Product Details
Place of Origin | Guangdong, China | Brand Name | TONON | |
Model Number | TN01681 |
Product Description
DATA:
Color: clear, opal, green, blue, bronze, lake-blue
Thickness: 1mm ~ 18mm
Maximum Width: 2100mm
Standard Width: 1220mm, 1560mm, 1820mm, 2100mm
Length: Not limited
Note: Special specs and color can be custom-made due to client's demand
Specificatioing of Foshan Tonon Bayer Polycarbonate Panel:
Thickness | Weight | Length | Width | Min Curving | Light transmission%( ± 3%) | |||||
mm | kg/ sqm | mm | mm | mm | Clear | Opal | Blue | Lake-blue | Brown | Light-green |
4 | 1 | 6000 | 2100 | 700 | 80 | 57 | 45 | 55 | 55 | 45 |
6 | 1.4 | 6000 | 2100 | 1050 | 79 | 56 | 36 | 50 | 53 | 42 |
8 | 1.5 | 6000 | 2100 | 1400 | 78 | 52 | 30 | 47 | 51 | 40 |
10 | 1.7 | 6000 | 2100 | 1750 | 77 | 44 | 25 | 42 | 48 | 35 |
Technical features of Foshan Tonon Bayer Polycarbonate Panel:
No. | Character istics | Unit | Data |
1 | Impact Strength | J/m | 850 |
2 | Light Transmission | % | 88 |
3 | Specific Gravity | g/cbm | 1.2 |
4 | Coefficient of Thermal Expansion | mm/m °C | 0.065 |
5 | Service Temperature | °C | -40 °C ~+120 |
6 | Heat Conductivity | W/ sqm * °C | 2.3~3.9 |
7 | Tensile Strength | N/sqmm | ≥ 60 |
8 | Flexural Strength | N/sqmm | 100 |
9 | Modulus of Elasticity | Mpa | 2400 |
10 | Tensile Stress at Break | Mpa | ≥ 65 |
11 | Elongation at Break | % | >100 |
12 | Specific heat | KJ/kg*k | 1.17 |
13 | Heat Deflection Temperature | °C | 140 |
14 | Effect of Soundproof | 10mm PC Hollow Sheet | Attenuation 20 db |
Colour samples of foshan tonon bayer polycarbonate hollow panel:
Note: There will be a little difference between samples and that of practical delivery in colour.
Features:
1. Light transmission:up to 88%
2. Impact resistant:80 times that of glass, 15 times thats of acrylic sheeting
3. Temprature service : -40°C ~~120°C
4. Light weight: only 1/12 of the weight of glass at same thickness
5. UV Protection
6. Fire retardance: Rated Class B1
7. Sound & Heat Insulation
Applications:
1) Roofing for swimming pool, shopping malls, commercial streets
2) Sunshade for stadiums and bus stops,gazebo, open-air carport
3) Lighting canopy for corridors, passages and subway entries
4) Flashing for bank ATMs, telephone box, gateways,garages
5) Sound and heat insulation wall for expressways and houses
6) Heat preservation material for agricultural greenhouse, flower greenhouse
7) Soundproof material for partitions
8) Unbreakable material for glazing windows, roof glazing
Our Factory Location:
Note: Foshan, a city where is near Guanghzou Port in Guangdong Province, China.
Clean And Maintenance: |
In case there is any filler, grease or paint adhered or polluted the surface of the pc sheet, remove it with a piece of soft cloth soaked with alcohol it become hardening. Never use the benzene, gasoline, acetone or carbon tetra chloride of cleaning, do not clean the sheet with any solvent exposed under direct sunshine or under forced bending, for it may crack. Generally wipe off the dust and dirt on the pc sheet by a piece of soft cloth or sponge soaked with neutral detergent first, rinse it with clear water thoroughly, and dry it with a piece of soft cloth finally. |
To Clients and Readers: |
This information and our technical advice whether verbal, in writing or by way of trails are given in good faith but without warranty, and this also applies where proprietary rights of third parties are involved. Our advices does not release you from the obligation to check its validity and to test our products to their suitability for the intended process and uses. The application, use and processing of our products and the products manufactured by you on the basis of our technical advice are beyond our control, therefore, entirely you own responsibility. Our products are sold in accordance with the current version of our General Conditions of Sales and Delivery. |
Length: not limited
Max width: 2100mm
Thickness: from 1mm to 18mm
Material: Makrolon Policarbonato resin from Bayer, Germany
Product line: 4 lines for hollow polycarbonate panel and 4 lines for solid polycarbonate panel.
Customized colors and dimensions available upon request contact us!
Contact Us
- Foshan Tonon Building Materials Co., Ltd.
- Contact namePeter Tsin Chat Now
- Phone86-0757-23602798
- AddressNo.2 industry in Shangliao of the town Beijiao, Shunde area, Foshan, Guangdong
