CMOS sensor wide angle car backup camera for parking assistance
car backup camera
TV system: PAL/NTSC |
Sensing area: 4.9mm*3.7mm |
Horizontal Resolution: 480 TVL |
Effective Pixels: PAL/628(H)*586(V) NTSC/510(H) * 496(V) |
Minimum Illumination: 0.2Lux |
Lens: 135 degree(Horizontal) |
View Angle: 170 degree(Diagonal) |
Sync. System: Internal |
S/N Ratio: >48dB |
Electronic Shutter: 1/50 to 1/100,000 seconds, 1/60 to 1/100,000 seconds |
Video Output: 1.0Vpp, 75Ohm |
White Balance: Auto |
Power: DC 12V |
Current Consumption: 110mA |
Operating Temperature: -20 ~ +80°C, 95% RH maximum |
Storage Temperature: -30~ +80°C, 95% RH maximum |
Waterproof: IP67 |
Remark:
1. With or without LED lights is optional
2. Plastic or metal without LED lights is optional
3. Plastic/white/brown/color box is optional
4. Connection: RCA or 4 PIN DIN is optional
1 x Camera
1 x video cable
1 x DC power cable
2 x screws
1 x 3M glue
1 x Manual
1 x Color box
Package: HTJ color box + outer carton,OEM/ODM service is available in HTJ
Shipment: By sea ,by air ,by express ,it's all up to you
1.) Manufacturer which specialized in Auto Electronics industry over 11 years
2.) With 10 professional R&D technicians and 8 experienced production lines
3.) More than 200 workers to support SMT workshop, cable workshop and assembly workshop
4.) Strict QC procedure, one-by-one quality checking, nearly no customer's complain during the passed orders.
5.) 3‰ prepare reserved quantity for every order in case of any rude shipment.
Shenzhen Hao Tian Jun Electronics Technology Co. Ltd (HTJ) was established in 2005.
Our factory is located in Dongguan,Guangdong, China.
Our main products are auto electronics, such as car DVRs, reversing systems, 360 degree panoramic driving and parking assistant systems, car cameras, etc.
We own two main brands "Car 360" and "Car Vision", mainly engaged in a 360 degree panoramic monitoring systems, car DVRs, and car special cameras , which have been widely recognized by customers all over the world.
As an integrated high-tech manufacturer:
1) We focus on R&D, Marketing, Production and Technical Services.
2) We apply TMS to extend and upgrade the OEM /ODM traditional model.
3) We strive to provide high-tech and high-quality products, and excellent service to meet customer demand.
4) We determine to become one of the world's most competitive automotive auto electronics product manufacturer.
With good corporate reputation, outstanding technical talent, humanized management system and mature market channels, we sincerely hope that we can work together for a brighter future.
Q1: What is your warranty terms?
A1: 12 months is guaranteed from the production date.
Q2: What is your MOQ?
A2: Depends on model you choose, small and trial order acceptable.
Q3: What is your lead time?
A3: 3-5 working days upon receipt of your payment.
Q4: What is your payment terms?
A4: T/T(Bank transfer), PayPal, Western Union, Money Gram.
Q5: Do you accept OEM or ODM service?
A5: OEM & ODM are welcomed.
Q6: Any certificate for your products?
A6: Yes, we have CE, FCC, RoHS certificate for your reference.
