Home > Products > Plate Compactors > Plate Compactor HZR-70
Plate Compactor HZR-70
USD $300 - $400
/ Piece
5 Pieces(Min.Order)
- 500 Piece / Pieces per Month
- Shanghai
- T/T
You May Like
-
Perkins T433072 - PISTON ASSEMBLY Genuine Engine Spare parts
-
Auto Balancing Turnover Spreader Beam for Car Frame/Chassis/Trailer/Flatbed Turning
-
SHANTUI JANEOO Sand making building ZSG120-5T
-
Main technical parameters of 30m concrete pump truck
-
207 Engine Hydraulic Filter HF6710 AT58368 86542664
-
1 Ton Garden Excavator For Sale
Product Details
| Place of Origin: | Shanghai, China | Brand Name: | DYNAMIC | Model Number: | HZR-70 |
Product Description
Specifications
Single-direction Plate CompactorFeatures:
1) The best choice for compaction of sandy soil, back fill and asphalt
2) Lowest vibration combined with highest compaction performance
3) Transport wheel available (option)
4) Rubber mat available for brick paving road (option)
Specification
| Model | HZR-70 |
| Weight kg(lb) | 89 (195) |
| Dimension mm (in) | 1100(43)*400(16)*950(37) |
| Plate size mm (in) | 590(23)*400(16) |
| Centrifugal force kn | 10 |
| Vibration frequency vpm (hz) | 5500 (92) |
| Forward travel m/min | 20-23 |
| Engine | Air-cooled, 4-cycle, Gasoline |
| Type | Honda GX160 Robin EX17 |
| Max. output kw (hp) | 4.0 (5.5) 4.2 (5.7) |
| Max. speed rpm | 3600 3600 |
| Fuel Tank liter (gal) | 3.6 (0.95) 3.6 (0.95) |
