1. &Specifications
¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯
Name |
Automatic Condiment Spices Powder Packing Machine |
Model |
HP200P |
Packing Speed |
20-50bags/min |
Filling Range |
150-500ml (Depending on the material) |
Filling Accuracy |
±2% |
Bag Size |
L40-250mm W30-180mm |
Roll Film |
Outer:≤300mm Inner:75mm Thickness:0.04-0.08mm |
Power |
2.3kw 220V AC |
Dimensions |
830*1060*2090mm |
Weight |
340kg |
Control System |
PLC or MCU |
Metering Methods |
Screw Metering, Measuring Cup, Weighing Metering |
Sealing Forms |
Middle, 3-sides, 4-sides |
Bag Way |
Plane, Pillow, Punching, Stand-up,Gusset Bag, etc |
Machine Housings |
Stainless Steel / Paint Spraying |
Working Ambient Temp. |
0-40°c |
Working Ambient Humidity |
20-90%RH |
|
Sealing Temperature Reference (Generally horizontal sealing temperature is higher than the vertical temperature of about 10%) | |
PAPER/PE, PET/AL/PE, PA/PE |
180°c |
PET/PE |
150°c |
BOPP/PE, BOPET/PE |
160°c |
PT/PE |
170°c |
Note: Due to the escalating changes condiment spices powder packing machine, the above technical parameters for reference only, to prevail in kind, please understand!
2. &Basic Introduction
¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯
- Functions
>The automatic condiment spices powder packing machine has bag making, metering, filling, sealing, cutting in one of the function, auto-complete all the packaging process, saving labor costs.
>Compact, small footprint, packaging speed, high yield, especially suitable for mass production of powder packaging use.
>Control Systems: Machine by Imported PLC, servo motors, display constitute the core of the drive control to improve the control precision, reliability and intelligence of the powder packing machine.
>Metering Filling: This machine adopts screw metering device, servo motor control screw rotation feeding, stable performance and easy to adjust.
- Expansion
>Expansion device: coding device, counting device, fill gas device, exhaust device, punching device, n-bag without cutting device, gusset bag device, feeding device, Etc.
- Scope
>The automatic condiment spices powder packing machine for milk powder, coffee powder, rice flour, protein powder, flour, instant food, nutritional food, masala powder, chilli powder, spices, paprika, spices, detergent powder, washing powder, pesticide powder, dye , enzymes, additives, feed and other powdered materials fast packaging.
3. &Feature
¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯
4. &Whole Show
¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯
5. &Packing Effect
¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯
6. &Bag Way
¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯
7. &Before Buying
¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯
- Propose before buying the automatic powder packing machine:
1) What’s packaging material?
(In order to select the appropriate metering device)
2) What’s the per bag packaging capacity?
(In order to select the appropriate metering device)
3) What’s the capacity for the machine (per minute)?
(In order to select the appropriate transmission device)
4) Packaging film width or packing bag size?
(In order to select the appropriate former)
5) Sealing form?
(In order to choose the suitable sealing device)
6) Whether you need additional device or if there are special requirements?
(In order to calculate the right price)
7) If there are special requirements for the power?
(The default configuration: 200V 50Hz / 380V 50Hz)
