Specifications
screw compressor for sale1.Air end-Atlas Copco
2.Motor-ZODA
3.Motor power:75kw/100hp
4.High efficiency screw air compressor
Atlas Copco(Bolaite) 100hp air screw compressor for sale
High quality configuration of screw compressor for sale
Parts |
Brand |
Air End |
Atlas Copco |
Intake Valve |
Hoerbiger (Austria) |
Solenoid Valve |
CEME (Italy) |
Temperature Sensor |
Hoerbiger (Austria) |
Pressure Sensor |
Huba Original (From Switzerland) |
Motor |
Qingjiang Motor |
Coupling |
Germany KTR |
Thermostat Valve |
Italy VMC |
PLC |
Schneider Electric (France), SIEMENS |
Minimal Pressure Valve |
Hoerbiger (Austria) |
Air Filter Element |
Germany MANN |
Oil Filter Element |
Germany MANN |
Oil Separator Element |
Germany MANN |
Bearing |
Sweden SKF |
Technical parameter of screw compressor for sale
Model |
|
BLT-100A/W |
||||
Free Air Delivery |
M3/min |
13.5 |
13.00 |
11.8 |
10.00 |
|
Working Pressure |
bar |
7 |
8 |
10 |
13 |
|
Compression stage |
|
Single stage compression |
||||
Cooling model |
|
Air cooling |
||||
Discharge temperature |
℃ |
≤The environment temperature +15℃ |
||||
Noise Level |
dB(A) |
62±2 |
||||
Transmission mode |
|
Belt transmission |
||||
Voltage |
V/Ph/Hz |
380V/3Ph/50Hz |
||||
Motor power |
KW/HP |
75/100 |
||||
Starting model |
|
Star-delta starting |
||||
External dimensions |
L |
mm |
1585 |
|||
|
W |
mm |
1170 |
|||
|
H |
mm |
1800 |
|||
Weight |
Kg |
1260 |
||||
Exhaust Pipe diameter |
inch |
G 2” |
||||
Products advantages of screw compressor for sale:
Item |
Description of parts |
Advantages of stationary air compressor |
1 |
Air end |
Atlas Copco air end,stable and reliable, lower energy consumption. |
2 |
Air filter |
Original efficient filter; Dust effect of 99.9%; Ensure effective dust compressor Filtration efficiency "3 microns." |
3 |
Vacuum loading and unloading valve |
Low pressure drop No large and heavy spring Simpler, less parts, maintenance |
4 |
Motor |
Efficient motor, IP54 protection, F class insulation, can work even in harsh environments |
5 |
Belts |
Belt adopts the world's top brands, high driving accuracy, good stability, long service life. |
6 |
Oil filter |
Imported oil filter, new 10 micron level (industry standard: 30 micron), better protection of air end. |
7 |
Pipeline |
import high-temperature materials hose, long-term operation without leakage. |
Our office in Shanghai
Cutting Workshop
Large models workshop
Testing Workshop
Applied industies
AC CEO Visit Bolaite factory in Shanghai
Packing for Air compressors
How to serve for you?
• Inquiry: Contact us by email, phone call, fax, Instant Messenger (Trade manager, MSN, Skype) and let us know your inquiry.
• Discussion: Specify the items you desire, confirm specification;
• Quotation: Prices offered and accepted.
• Place order as per contract or discussion.
• Perform invoice( sales contract ) In duplicate confirmed and kept by both sides.
• Payment settled.
• Order completed under our arrangement.
• Goods shipped as per contracted term.
• Goods arrive at local port or warehouse, depending on contracted term.
• Support & re-ordering.
FAQ(Frequency Asked Questions),to provide you a suitable model,pls confirm:
1.Working pressure(bar/Mpa/psi)?
2.Air delivery(CFM/m3/min)?
3.What's the compressor used for?
4.Voltage in your couontry(V/PH/HZ)?
5.A whole equipment includes: air compressor,air dryer,air filters and air tank.
Any need,pls don't hesitate to contact us! Let's make better life together!
