Specifications
detailed info of hobby cnc milling machine1)stepper motor
2)1.5KW water cooled spindle
3)Fulling inverter
4) square guide
2015 hot new product hobby cnc milling machine
simple of hobby cnc milling machine :
Machine Parts of hobby cnc milling machine :
Product Description of hobby cnc milling machine :
1) hobby cnc milling machine adopts import liner square guide,double four ball slider,so it can bear big gravity,move steady,ghigh accuracy,longevity,import ball with high accuracy,and precision knife,so it is suitable for batch processing kinds of materials.
2) hobby cnc milling machine can compatible many kinds of CAD/CAM design software,such as tytp3,artcam. castmate and so on.
3) hobby cnc milling machine is wholly break away from remote operation USB connector DSP operating system.Lever operation so it is easily to operate,humanity design and adopts special smart budget law so it can make the motor play full potential.Realize high speed processing.curve and straight line synchronize,the curve line is more perfect.And do not occupy computer memory so it can realize cutting spindle’s start-stop system.
4)Six vacuum worktables,so electric wood carving tools can absorb different size panel.vacuum pump can select import brand without oil so it can solve the problem when during winter the water circulation vacuum pump is difficult to change and add water.
5) hobby cnc milling machine use high speed drive stepper motor and drive implement.Y axis adopts double motor drive,so it can make the high speed at 35 meters /minute operate with the cutting spindle so the carving speed is quickly.
Applicable industries of hobby cnc milling machine :
hobby cnc milling machine is used for carving the wood,drilling hole,guide margin,cutting,processing the wave plate,artificial door,non-painting door and so on.
Technical parameter of hobby cnc milling machine :
Model |
C13 |
C16 |
C18 |
X working area |
1300mm |
1600mm |
1800mm |
Y working area |
1300~3000mm |
1600~3000mm |
1800~3000mm |
Z working area |
200mm |
200mm |
200mm |
Table size |
1480~3500mm |
1780~3500mm |
1980~3500mm |
Max feeding |
>25m/min |
>25m/min |
>25m/min |
Work-holding |
vacuum table |
vacuum table |
vacuum table |
Interface |
USB |
USB |
USB |
Command |
G code *.u00*.mmg*.plt |
G code *.u00*.mmg*.plt |
G code *.u00*.mmg*.plt |
Surroundings for software |
DSP |
DSP |
DSP |
Power(not include the spindle) |
1840W |
1840W |
1840W |
Power |
AC380V/50HZ |
AC380V/50HZ |
AC380V/50HZ |
Main axle power rate |
4.5kw(Italy air cooling) |
4.5kw(Italy air cooling) |
4.5kw(Italy air cooling) |
Main axle rotating speed |
0-24000rpm/min |
0-24000rpm/min |
0-24000rpm/min |
Word mode |
leadshine or Yaskawa |
leadshine or Yaskawa |
leadshine or Yaskawa |
Machine weight |
1000kg |
1300kg |
1600kg |
FAQ:
After sales-service of hobby cnc milling machine :
1)one year free warranty under nomal use and we give maintance for 18 months.
2)first class engineer give 24 hours service on internet and telephone ,free instructions and problem solving.
3)free training to make sure you master the operating of shape cutting machines wood china supplier .
