the cheapest professional manufacturer marble cutting machine
Machine parts of marble cutting machine:
Samples of marble cutting machine:
Performance feature of marble cutting machine:
1)marble cutting machine adopts Industrial production model,heavy all-steel welded,temperating aging treatment,solid and can not change the shape.
2)marble cutting machine adopts Taiwan liner guide which is contact with the bearing surface,so long time use the precision will be high.
3)marble cutting machine uses Germany double-nut automatic anti-backlash ball screw.
4)marble cutting machine has High speed driver,so it has high speed and power.
5)marble cutting machine adopts Dust-protected oiling structure,so it make sure the machine running long time.
6)marble cutting machine has Break point and cutting continued carving,so it can engrave at any angle.
7)marble cutting machine can compatible many kinds of CAD/CAM design software,such as tytp3,artcam. castmate and so on.
8)marble cutting machine has High power AC water cooling spindle,so it can process hard material efficiently.
Applicable industries of marble cutting machine:
marble cutting machine is used for carving marble,granite,glass,muyu-stone and so on hard materials.
Technical parameter of marble cutting machine:
Model |
BDX-S90 |
BDX-S12 |
BDX-S15 |
BDX-S18 |
X working area |
900 |
1200 |
1500 |
1800 |
Y working area |
1200-1500mm |
1200-1500mm |
1200-3000mm |
1200-3000mm |
Table size |
1080-1800mm |
1380-3000mm |
1680-3500mm |
1980-3500mm |
Max area of Z axis |
300mm |
300mm |
300mm |
300mm |
Highest running speed |
12m/min |
12m/min |
12m/min |
12m/min |
Highest engraving speed |
8m/min |
8m/min |
8m/min |
8m/min |
Precision |
0.005mm |
0.005mm |
0.005mm |
0.005mm |
Max feeding height |
350mm |
350mm |
350mm |
350mm |
Spindle power |
5.5kw/main axis |
5.5kw/main axis |
5.5kw/main axis |
5.5kw/main axis |
Rotated speed of the spindle |
0-24000rpm/min |
0-24000rpm/min |
0-24000rpm/min |
0-24000rpm/min |
Working model |
stepper |
stepper |
stepper |
stepper |
Machine weight |
1000kg |
1300kg |
1600kg |
2000kg |
More products about cnc router:
If any further details you need, please contact us with "contact" buttom.
Please feel free to contact us,we will reply within 24h!
We want to know:
1 How much the spindle power you need
2 What materials do you need to process
3 The size and thickness of your materials
Our factory:
