High Accuracy BDXS-3030 Automatic Gem Cutting Machine

Jinan Big Dipper CNC Machinery Co., Ltd.
High Accuracy BDXS-3030 Automatic Gem Cutting Machine thumbnail-1
High Accuracy BDXS-3030 Automatic Gem Cutting Machine thumbnail-2
High Accuracy BDXS-3030 Automatic Gem Cutting Machine thumbnail-3
High Accuracy BDXS-3030 Automatic Gem Cutting Machine thumbnail-4
High Accuracy BDXS-3030 Automatic Gem Cutting Machine thumbnail-5
High Accuracy BDXS-3030 Automatic Gem Cutting Machine thumbnail-6
High Accuracy BDXS-3030 Automatic Gem Cutting Machine photo-1
High Accuracy BDXS-3030 Automatic Gem Cutting Machine photo-2
High Accuracy BDXS-3030 Automatic Gem Cutting Machine photo-3
High Accuracy BDXS-3030 Automatic Gem Cutting Machine photo-4
High Accuracy BDXS-3030 Automatic Gem Cutting Machine photo-5
High Accuracy BDXS-3030 Automatic Gem Cutting Machine photo-6
US$ 500 - 10,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Stone Engraving Machine
Use:
Other, jade,marble and so on
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Stone Engraving Machine
Use Other, jade,marble and so on
Production Capacity 500sets/month
Place of Origin Shandong, China
Brand Name Dipper
Model Number BDXS-3030
Voltage AC220V50-60HZ
Power(W) 2.2w
Dimension(L*W*H) 300*300*100mm
Weight 100kg
Certification CE
Warranty 1 YEAR
After-sales Service Provided Engineers available to service machinery overseas

Specifications

BDXS-3030 automatic gem cutting machine:
1.CE,ISO
2:2.2KW water cooling spindle
3:stepper driver and motor
4.fuling inverter

High accuracy BDXS-3030 automatic gem cutting machine

High accuracy BDXS-3030 automatic gem cutting machine

Machine parts of gem cutting machine:



High accuracy BDXS-3030 automatic gem cutting machine





Samples Show of gem cutting machine:

High accuracy BDXS-3030 automatic gem cutting machine



Performance feature of gem cutting machine:

1)It adopts international advanced precision guide rail,the slider pre-tightened device(make sure the slider no space).Germany import ball screw,so make sure the machine move steadily,high engraving accuracy,and little vibration.

2)The whole machine adopts iron bed and dragon door.The machine steady and run high precision.

3)800w water cooling constant power variable frequency motor,capability strong and less noisy.

Curving and straight line control independently.

4)High speed data transmission.

5)It adopts micro control system,breakpoint continued carving and restore engraving when power supply drop,specify the G code carved and so on advantage.(optional handle operation system,off computer operate).



Applicable industries of gem cutting machine:

It is mainly used for jewelry relief processing,pper,aluminum,zinc and so on metal engraving.



Technical parameter of gem cutting machine:

Model

BDXS-3030

BDXS-4040

Table size

350mm*350mm

500*500mm

Working size

300*300*100mm

400*400*100mm

Engraving speed

7000mm/min

7000mm/min

Resolution ratio

0.0001mm/step

0.0001mm/step

Spindle

frequency conversion water-cooled

frequency conversion water-cooled

Main axle rotating speed

0~24000rpm

0~24000rpm

Main axle power rate

1.5w

2.2w

Shank diameter

ø3.175/ø4/ø6

ø3.175/ø4/ø6

Machining instruction

G code /HPGL 3D

G code /HPGL 3D

Power

1.5kw

2.2kw

Power supply

AC220V50-60HZ

AC220V50-60HZ



 More products about cnc router:

High accuracy BDXS-3030 automatic gem cutting machine
