Gas station Bagged Ice Storage Bin for Ice Merchandiser
Bagged Ice Storage Bin is widely use in Gas stations, wine stores, supermarkets e.t.c for bagged cube ice or flake ice.
Option:
The Bagged Ice Storage Bin can be made with double-wall insulation which allows a proper air-circulation around the ice even when the ice storage is completely full. Of course each ice storage is equipped with an air-cooling unit keeping the storage temperature at around - 5 degrees or -12 degrees as requested.
Refrigeration: Fan Cooling System or Cold Wall System is optional.
Door: Solid door or Glass door is optional.
PRODUCT INFORMATION:
1. Material: Painted galvanized steel foamed in polyurethane insultation. S/S is optional.
2. Temperature: -5 C or -12 degrees as requested, it can be changed as customer requirement.
3. Door: With heavy duty hinge, Solid door or glass door is optional
4. Fan cooling system with Automatic defros, cold wall refrigeration system is optional.
5. Heavy duty caster wheel to make the freezer easily to move, bullet feet is optional
6. Voltage and frequency can be changed as customer's requirement.
Specification of Ice Freezer DC-380:
Model |
DC-380 |
Size |
1220*890*1930mm |
Packing size |
1280*950*2030mm |
Material |
Painted Galvanized Steel |
Temperature |
-5 OR -12 degrees C |
Refrigeration |
Fan cooling OR Static cooling |
Compressor |
Embraco Brand |
Storage capacity |
About 120 bags, 8lbs(3.6kgs)/bag for Static cooling system |
Door size |
685*685mm *1pc |
Loading |
10PCS/20’GP; 21PCS/40’GP |
MOQ |
1 *20’GP container |
Refrigeration System:
We can make our Bagged Ice Storage Bin series with Direct cooling system (Cold Wall System) with pure copper pipe, or Fan Cooling Sytem. As per our experience, Direct cooling system is better for out door use.
Digital Temperature Controller: temperature standard is -12 degrees, -5 degrees is optional. Customized is acceptable.
Compressor: we use imported Embraco brand for our product, R404a refrigerant, better for refrigeration.
Bottom: can be with castors, bullet feet, or do not need.
Gas station Bagged Ice Storage Bin series:
We have some diffrerent models with different capacity, single door or double doors, size and temperature can be customized.
Package will different according to order quantity, for sample, we suggest hermetic plywood case, for buk cargo, wooden case is better, for container load, use pallet for more quantity loaded.
*manufacture polyurethane insulation panels
*OEM design and manufacture cold room,ice merchandiser,blast freezer, water chiller
*provide oversea installation service
Dachang company is located in Dongguan,China, equiped with 30000 square meter of modern workshop and imported CUSBER and OMS production lines for polyurethane insulation panels.Dachang company adheres to the scientific production,marketing and management conception,keeps improving production technology and R&D technology, and continuous to expand our production line.Besides polyurethane insulation panel and cold room, we also produce blast freezer,water chiller, ice merchandiser etc. related commercial refrigerated products.Products are hot sale in HK,Macau,USA,Australia,Thailand,France,Netherland,Benin,Ghana,Nigeria etc., clients are very pleased with our product and service.
For our better quotation, please give us the specification of products you need,like size, temperature, ambient temperature of place where product will be used e.t.c.
Hope will have a good cooperation in the near future.
