drinks cooling room (glass door with heater)
cooling room Product Features :
1. The drinks cooling room is durable in use, color lasting & coated layer keeping.
2. It is made with Bayer polyurethane material by high pressure foaming. The cold room panel
density is up to 40kg/m3 or above.
3. The internal cold room floor panel of our cold room is made by 1.0mm galvanized steel
and durable for anti-scratch.
4. The hinged door panel of our coldroom is made by heavy duty door hinge, heavy duty door lock and hydraulic door closer.
5. The connection of our cold room panels are made with PE sealing rubber which is with high
quality sealing.
6. The connection of our cold room is with cam lock construction and excentric fasterners for
tight connection and sealing of the cold room
cooling room Product information:
Dimension |
Length (m) *Width (m)*Height (m) According to client's requirement . |
Panel |
polyurethane insulation panel,43kg/m3, fire retardant |
Foaming material |
BASF |
Panel thickness |
50mm,75mm,100mm,150mm,200mm |
Steel cover |
stuccom embossed aluminum,painted galvanized steel,stainless steel,PVC stell |
Panel connection |
cam lock type, use hexagonal key to assemble and disassemble |
Type of door |
hinge door, convex door, sliding door |
Temp.of room |
-45~+20 degree, optional |
Purpose of cold room |
fruit,vegetable,flower,fresh/frozen meat etc |
Refrigeration unit |
Copeland / Bitzer / Sanyo etc |
Refrigeration type |
air cooled / water cooled |
Fittings |
all necessary fittings are included, optional |
Place to assemble |
indoor/out door(concrete construction building/steel construction building) |
Voltage |
220V/50HZ, 220V/60HZ, 380V/50HZ optional |
we are a professional manufacturer,which help our clients to customize the cooling room . Pls answer us the your detailed requirement. Tks!
cooling room Details
the switch to control the light and door heater
the dipped plastic shelf for the cooling room
plastics-dipping shelf (5 pcs/set) (L:726*W:600mm)
cooling room structure
cooling room panel:
| No. | Inspection Item | Unit | Technology requirement | Inspection result |
| 1 | Density | kg/m3 | 32~50 | 43 |
| 2 | Compressing strength(10%deformation) | Kpa | ≥ 160 | 200 |
| 3 | Bending Stregth | Kpa | ≥ 245 | 331 |
| 4 | Absording rate | % | ≤ 4 | 3 |
| 5 | Heating coefficient | W/m.k |
0.024 | 0.021 |
| 6 | Average burning time(vertical) | S | ≤ 30 | 3 |
| 7 | Average burning height(vertical) | s | ≤ 250 | 250 |
Every panel is male (convex) and femal(concave) type,cam locks are pre-burried inside the panels,use a key to lock them together.
our panel advantage :
1. Our panel foaming material is Italy Brand BASF . The whole panel average density above 40kg/m3 which enable the panel with better thermal conductivity of 0.021W/(m.k). The national standard is 0.024W/(m.k), which mean our panels will save the energy consumption of 12.5% than national standard.
2.All the panels we produce are with fire retardant, self-Extinguish, Fireproofing Grade is B1. It refers to the safety problem.
3.The steel sheet we purchase from Baosteel and POSCO which are the biggest steel factories in the world, they promise the painted galvanized steel they produce will not fade in 15~20 years.
4. Gasket is around the edge of each panel , when panel lock together,the cool air will not leak,and the hot air can not come in .It enable the cold room with better air-tightness. So our panel is with excellent thermal insulation effect . It can save much more energy consumption.
non slip floor for cooling room
cooling room condensing units: (Integrative Unit)
ZANOTTI
Feature:
1. Adopt inpotred Hermetic piston type compressor
2. Imported branded MAVIB,EBM Fan
3. Capillary expansion system , Refrigerant Gas R404a
4. Intelligent automatic defrosting system ,which can save much more energy consumption.
Our compressor is with Defrost sensor,which decide the defrost time automatically . So it can reduce the energy consumption .
Fan for cooling room
production line for our cooling room
Package for our cooling room
Some of our cooling room Project :(Domestic and Overseas )
Take part in the Exhibition every year:
