supermarket cold room with glass door for beverage and food storage
supermarket cold room with glass door is a new product with various standard dimension sizes.
The storage capacity of it may be specified or selected according to customer's requirements. The storage temperature of the coldroom is displayed and controlled by digital thermostat for precise control temperature and temperature adjustment to achieve the utmost energy efficiency and perfect storage of food.
supermarket cold room with glass door Features:
1.Using all parts of the main foreign brands, running more secure;
2.A unique way of cooling than traditional high-efficiency by about 30%;
3.To adopt environment-friendly refrigerant and fluorine-free refrigerant;
4.Mute design, low noise and give you a quiet office space;
5.Condensation unique: half of the natural convection, half of the air, even if the wind blocking dirty condenser, compressor' is not easy to cause damage;
6.The production of stainless steel liner;
7.Round cavity design, easy to clean;
8.Outside the door silicone door seals tight blockade of air-conditioning;
9.R232 interface (optional) to help data analysis;
10.The removable cleaning dust,
11.According to the domestic high and wide doors designed for the handling and do not have to put in place to worry about;
12.PU extra-thick insulation so that heat and strengthen the structure;
13.With lights and shelvings
supermarket cold room with glass door specification:
Glass Doors |
50mm panel(2~10C) |
75mm panel(0~-5C) |
100mm panel(-5~-20C) |
1 DOOR |
905*950*>1965mm |
955*950*>2015mm |
1005*950*>2065mm |
2DOORs |
1663*950*>1965mm |
1713*950*>2015mm |
1763*950*>2065mm |
3DOORs |
2421*950*>1965mm |
2471*950*>2015mm |
2521*950*>2065mm |
4DOORs |
3179*950*>1965mm |
3229*950*>2015mm |
3279*950*>2065mm |
5DOORs |
3937*950*>1965mm |
3897*950*>2015mm |
4037*950*>2065mm |
6DOORs |
4695*950*>1965mm |
4745*950*>2015mm |
4795*950*>2065mm |
7DOORs |
5453*950*>1965mm |
5503*950*>2015mm |
5553*950*>2065mm |
8DOORs |
6211*950*>1965mm |
6261*950*>2015mm |
6311*950*>2065mm |
9DOORs |
6969*950*>1965mm |
7019*950*>2015mm |
7069*950*>2065mm |
10 DOORs |
7727*950*>1965mm |
7777*950*>2015mm |
7827*950*>2065mm |
supermarket cold room with glass door introduction:
1. supermarket cold room with glass door panel
1)Panel test specification
| No. | Inspection Item | Unit | Technology requirement | Inspection result |
| 1 | Density | kg/m3 | 32~50 | 43 |
| 2 | Compressing strength(10%deformation) | Kpa | ≥ 160 | 200 |
| 3 | Bending Stregth | Kpa | ≥ 245 | 331 |
| 4 | Absording rate | % | ≤ 4 | 3 |
| 5 | Heating coefficient | W/m.k |
0.024 | 0.021 |
| 6 | Average burning time(vertical) | S | ≤ 30 | 3 |
| 7 | Average burning height(vertical) | s | ≤ 250 | 250 |
2) supermarket cold room with glass door Panel advantages:
1. Our panel foaming material is Germany Brand BASF . The whole panel average density above 43kg/m3
which enable the panel with better thermal conductivity of 0.021W/(m.k). The national standard is 0.024W/(m.k), which mean our panels will save the energy consumption of 12.5% than national standard.
2.All the panels we produce are with fire retardant, self extinguish, Fireproofing Grade is B1. It refers to the
safety problem.
3.The steel sheet we purchase from Baosteel and POSCO which are the biggest steel factories in the world, they promise the painted galvanized steel they produce will not fade in 15~20 years
4.Gasket is around the edge of each panel , when panel lock together,the cool air will not leak,and the hot air can not come in.
2. supermarket cold room with glass door parts
1)Plastic coated shelf
2)Light and glass door heating tube switch
3. supermarket cold room with glass door refrigeration unit
4. supermarket cold room with glass door installation
5. supermarket cold room with glass door package
panel and door are packed with the PE film and bubble paper , it is convenient and save cost.
6. supermarket cold room with glass door panel production procedure
supermarket cold room with glass door project:
supermarket cold room with glass door exhibition:
supermarket cold room with glass door certificate:
supermarket cold room with glass door Factory picture:
