Specifications
-CCTV surveillance system-2.4G Security Camera kit
-Can support 4 cameras max
-Automatic cycle surveillance
Feature Of CCTV surveillance system
*2.4G Security Camera kit
*One receiver plus two cameras
*Can support 4 cameras max.(quantity optional)
*Alloyed shell,weather proof function for outdoor use
*Built-in microphone for audio monitoring
*Min 100 merers transmission distance without block
*Automatic cycle surveillance,selectable cycle channel and time
Camera Specification
Frequency: 1CH:2414MHz,2CH:2432MHz,3CH:2450MHz,4CH:2468MHz
Imaging Sensor: 1/3 inch OMNIVISION Color CMOS
Horizontal Resolution: 380TV Line
CMOS Total Pixels: 628 x 582 (PAL) / 510 x 492 (NTSC)
View Angles: 62 degrees
Minimum Illumination: 2.0Lux
Gain Control: Automatic
Transmission Power: 10mW
Consumption Current: 80 mA
Modulation Mode: FM
Bandwidth: 18M
Operating Range: 30m/100m (Obstructed / Unobstructed)
Power: DC 8V ;built-in li-battery
Operating Temperature: -10oC ~ +40oC
Operating Humidity: 85%RH
Dimension(WxLxH):36mm ×25mm ×28mm
Weight: 60g
Monitor Specification
Frequency: ISM 2,400 - 2,483MHz
Antenna: Omni-directional antenna
Channel: 1-4 (Flip-type switch)
Intermediate Frequency: 480MHz
Frequency Stabilization: +/- 100KHz
Demodulation Mode: FM
Video Output: 1Vp-p@75 ohm, S/N>38dB
Audio Output: 1Vp-p@600 ohm
Power:DC 9V/12V
Operating Temperature: -10oC ~ +40oC
Operating Humidity: 85%RH
Dimension(WxLxH): 110x80x20 mm
Weight: 130g
Standard Package Content
Gift Box Size : 19.5x18x8cm
Carton Box Size:41.5x37.5x42cm
1 gift box : 1 Unit
1 Carton Box : 20 sets
Gross Weight :12.5kg/ carton
Net weight : 11.5 kg/Carton
Net weight : 0.8 kg/Carton
