Special Occasion Pipi Mini Snake Inspection Camera With 3.45inch Monitor

Special Occasion Pipi Mini Snake Inspection Camera With 3.45inch Monitor thumbnail-1
Special Occasion Pipi Mini Snake Inspection Camera With 3.45inch Monitor photo-1
Negotiable MOQ: 10 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
GTW
Model Number:
ZJ860
Contact Supplier Request Quote Chat Now
Shenzhen Gtw Security Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name GTW
Model Number ZJ860
Type Analog Camera
Style Mini Camera
Sensor CMOS
Technology Pinhole
Special Features Waterproof / Weatherproof

Specifications

3.45 inch colour LCD display
4 pieces AAA battery
Support 32GB TF Card
Can be used as U disk
high quality

model: ZJ860

Features:


*4 Channels Wireless Receiving Function
*MP3 Player
*Take photos and record videos
*Can play back pictures, recorded video
*Can be used as U disk
*Support 32GB TF Card
*3.45 inch colour LCD display
*Picture resolution:JPEG 640*480
*Video resolution: AVI 640*480
*Image format:JPEG
*Video format:MJPEG
*Built-in Lithium Battery
*4 pieces AAA battery
*300k High definition CMOS sensor
*4 white LED lights
*The clearness of the LED Fill Light can be adjusted



Camera Specification:



Electrical parameters:

LCD and Video Parameters:

Screen size and resolution:320x240RGB :TFT 3.45inch

AV Output system:Standard PAL / NTSC output

LCD System:PAL/NTSC  switch automatically

Video format:640x480/AVI  25- 30 frames / sec

Video Compression Format:MJPEG-AVI Max 30pfs

Support file format:MPJEG-4/AVI

Video output level:0.7-1.2vp-p

Speaker Output:800MW( Max volume )

Audio format:MP3

Picture:File Format:JPG/JPEG/

RF part:

Receive frequency:ISM2400—2483MHZ

Channel interval:18MHZ

Intermediate frequency:480MHZ

Modulation mode:FM

CH number:4 Channels  CH1;2414MHZ,CH2:2432MHZ,CH3:2450MHZ,CH4:2468MHZ

Rx sensitivity:-70dBM

Memory Card:Internal flash range from 128MB to 4GB,according to customers’s requirement

Storage way:TF Card and NANAD Flash( Internal memory)

TF Card:Support 128M to 32GB(Max)

Operation system:

IBM-PC:Windows 98SE,ME,2000,XP

USB:USB 2.0

Operation system:Chinese/English

Work Voltage:

DC5V:DV 5V for USB Port and built-in Li battery

Li battery capacity:700mah  40-70Minutes continuously with full battery

Work current:580MA  MAX

camera basic parameters :

Focus:40-60MM

View angle:40—50 degree

Definition:380  TV lines

Pixel:0.3 Mega

Sensor size:1/6 Inch

Transmit frequency:ISM2400—2483MHZ

Modulation mode:FM

Channel:4Channels CH1:2414MHZ,CH2:2432MHZ,CH3:2450MHZ,CH4:2468MHZ

Channel interval:18MHZ

Transmission power:18dB

Work voltage:DC 6V 4pcs AAA Dry battery

Work current:180MA  MAX



Monitor Specification:



special occasion pipi mini snake inspection camera with 3.45inch monitor



Packing:



special occasion pipi mini snake inspection camera with 3.45inch monitor
