auto/Bus A/C compressor electric magnetic clutch assembly DC24V 60W
| Model | DL235-210-2A2B |
| Material | 10''low carbon mild stell |
| COIL |
100% copper wire , φ0.71mm copper wire |
| coil seal | high temperature epoxy resin |
| Diameter of strap wheel / Groove model | φ235-210-2A2B |
| Voltage | DC24V |
| Minimum pull-in voltage | DC15V |
| Power | <=60W |
| MIN static Torque | 450 N.m |
| Operating Revolution | 500-3500r.p.m |
| Max.Speed | 3800r.p.m |
| guarantee | 12months |
| Appicable comperssor | BITZER 4U~4NFCY,BOCK FKX-40 |
|
Jiujiang Qiyuan Mechanical Electronic Instrument Limited Company address:JIUJIANG CITY, JIANGXI PROVINCE, CHINA. | |
| company introduce | Our company was establish in 2002, has 12000 square meters factory area, including 10000 square meters construction area, more than eighty employee. It Owns more than 50 sets of various processing equipment and one assemble product line, afforded50000 clutch per year. |
| main products | auto air ditioner (a/c)electromagnetic clutch for compressor BITZER,BOCK,THERMO KING,HISPACOLD,VALEO,MANDO,XH,AK... |
| Certificate |
1.CASE(Auto air conditioner professional Committee of Society of Auto Engineering of China) 2.ISO9001:2008 |
| Main market | Southeast Asia,Middle East,Africa,South America,Europe, |
| Chief client | UNI-DRIVE,UNICOOL,A-TECH,A.C.R,COACH AIR,RICARBUS....ZHENGZHOU YUTONG,XIAMEN KING LONG |
| Applicable bus | YUTONG, HIGER , KING LONG, GOLDEN DRAGON,ZHONG TONG, ANKAI, YANG MAN,DAEWOO,NEOPLAN,HYUNDAI,Refrigerated Truck. |
| Our service |
1. accept OEM,if you did not find what type you want,pls send us drawing or sample 2.marking on clutch body for free 3.12 months after-sale guarantee 4.any technical question pls let us know,we will do our best to help you. |
| Production package | 1 packed/standard export carton, 5 layers corrugated carton bundled with packing belt,and will use wood pallet if quantity >16sets |
1.Why choose us?
answer:we are factory with15 years experience,professional technical team. ISO9001:2008 quality, and our best service.
2.How about the package?
we use 5 layers corrugated carton and filled with foam board,1set /carton,and bundled with packing belt.
if quantity large,we will use wood pallet to package.
when you have special require on package,pls kindly let me know,I'll do my best to support you.
3.What about the deliver time?
In common,if your quantity not so large,we have instock,will need only 2-3workdays to assemble.
or we will let you know the production cycle when you place order.
4.what about the guarrantee for after-sale?
dear,we can offer you 12months guarantee,it means that when clutch body or coil broken,you can back to us to change a new one,but base on you bear the freight cost both come and back.
many more other question,please contact me,I'll do my best to support you.thanks.
NO.1,ANTAI ROAD, AUTOMOBILE INDUSTRIAL PARK, DEVELOPMENT ZONE, JIUJIANG CITY, JIANGXI PROVINCE, CHINA.
zip code:332000
TEL:86-792-8252568 whats app /mobile: 0086 135 1702 8125
