Help CenterLiquid Tight Flexible Steel Conduit
US$ 0.35 - 6.5
MOQ: 500 Meters
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
sea wave
Model Number:
HL-JSB
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
PVC Coated Flexible Steel ConduitUS$ 0.35 - 6.5MOQ: 500 Meters -
Flexible Galvanized Steel ConduitUS$ 0.34 - 6.46MOQ: 500 Meters
-
Wholesale 38mm Corrugated Female Plastic Rigid PVC Conduit BushingUS$ 0.045 - 0.05MOQ: 100 Pieces
-
Custom High Quality Different Types Of Connectors For Flexible HoseUS$ 0.045 - 0.05MOQ: 100 Pieces
-
High Intensity Flexible Metal Waterproof Conduit Fittings From ChinaUS$ 0.045 - 0.05MOQ: 100 Pieces
Place of Origin
Zhejiang, China
Brand Name
sea wave
Model Number
HL-JSB
Type
Flexible
Material
PVC
Material: |
(Lining) galvanized steel strip special insulation treated. |
Color: |
Black & Grey & Etc. |
Working temperature: |
-10°C-- +80°C, 100°C in short time. |
Characteristics |
1. It has excellent performance of waterproof, insulation and tensile property. |
Usage field: |
Power plant, Power transmission system, communication system, building factory, railway, train, transportation system project, air conditioner, various machines, automates controlling plant. And protecting the electrical wire or cable outside the construction and plant. |
Using method: |
Inserting the wire or cable into the conduit and the equipped with the HS-JSB connector. |
This JSB type conduit is liquid tight with the very thick PVC coated. We can supply from the size 1/2" to 2", and this year we will try to the size above 2" for new production. The package is as following pic showed
| Model | Specification | OD and tolerance(mm) | Bending(mm) | Max axial direction tensile(Kg) | Package unit(m) | |
| Metric | British system | |||||
| HL-JSB-16 | Φ16 | 1/2″ | 21.2±0.35 | 85 | 940 | 50 |
| HL-JSB-19 | Φ19 | - | 24.5±0.40 | 95 | 1120 | 50 |
| HL-JSB-20 | Φ20 | 3/4″ | 25.5±0.40 | 100 | 1180 | 50 |
| HL-JSB-25 | Φ25 | 1″ | 31.7±0.45 | 120 | 1450 | 25 |
| HL-JSB-32 | Φ32 | 1 1/4″ | 39.6±0.50 | 150 | 1885 | 25 |
| HL-JSB-38 | Φ38 | 1 1/4″ | 46.6±0.60 | 180 | 2240 | 20 |
| HL-JSB-51 | Φ51 | 2″ | 59.5±1.00 | 220 | 3000 | 10 |
