Help Center9W New Retrofit LED Tube
US$ 13 - 18
MOQ: 50 Pieces
Key Specifications
Get Latest Price
LED Light Source:
3528 SMD
Warranty(Years):
3
Input Voltage(V):
AC100-240V
Payment & Shipping
Payment Methods:
Port of Shipment:
Xiamen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
IP54 Bracket LED Tube 40w 4feetUS$ 26.55 - 29.5MOQ: 1000 Pieces -
CE T8 LED TUBE 18W LED LIGHTUS$ 8 - 12MOQ: 25 Pieces
-
1.2m T8 Led Tube Light, 18w, CE ApprovalUS$ 8 - 12MOQ: 25 Pieces
-
4ft UL LED Tube T8US$ 14 - 16MOQ: 100 Pieces
-
High Quality Full Plastic 4ft 18W T8 LED Tube ULUS$ 12 - 14MOQ: 25 Pieces
LED Light Source
3528 SMD
Warranty(Years)
3
Input Voltage(V)
AC100-240V
Lamp Power(W)
9
Lamp Luminous Flux(lm)
980
Lamp Luminous Efficiency(lm/w)
109
Working Temperature(℃)
-20, 40
Working Lifetime(Hour)
50000
Lamp Body Material
PVC
IP Rating
IP44
Certification
CE
Place of Origin
Fujian, China
Brand Name
GOPRO
Model Number
Other, T8, GPT80608XX
Specifications
9W Tube T8,1) 792+-10%
2) 144pcs white led, 6500k
3) CE & RoHs certificate
4) Lifespan 30000hrs
8W T8 led tube lights
T8 LED Tube Features:
- LED tube adopt the latest LED technology, which can save 70% power consumption.
- LED as the third generation Semiconductor lighting contain
-
many advantages as below:
(1) High luminous efficiency: 80%-90%.
(2) High luminous quality: none thermal, none EMI.
(3) Low power consumption: single LED between 0.05W to 1W, which is 1/8-10
compared to normal Incandescent.
(4) Lifespan: 30,000hours under 30% brightness fading.
(5) Appearance specification: small and various size, flat package, which can apply to dot, line, surface application.
(6) Driver: 1.5-2V/ 20-85mA
(7) CE& RoHS compliance/recycle
(8) Fast response: available for high frequency operation.
T8 LED Tube Specifications:
| Item | Power | Part No. | LED Qty. | Dimension(mm) | Weight (pc/g) | Color Temperature | Package Size(cm) | Qty/box | Input Voltage (V) | Power Factor | Luminous Flux (LM) | |
| DIA. | Length | (K) | ||||||||||
| 1 | 9w | GPT806092x | 144 | 26 | 602 | 190 | 2700-10000 | 713*240*240 | 25 | AC85-300v | >95 | 792±10% |
| 2 | 15W | GPT812152x | 276 | 26 | 1212 | 350 | 2700-10000 | 1335*240*240 | 25 | AC85-300v | >95 | 1518±10% |
| 3 | 12w | GPT809122x | 189 | 26 | 906 | 260 | 2700-10000 | 935*240*240 | 25 | AC85-300v | >95 | 850±10% |
| 3 | 25W | GPT815252x | 432 | 26 | 1512 | 450 | 2700-10000 | 1635*240*240 | 25 | AC85-300v | >95 | 2376±10% |
8W T8 LED Tube:
Part no. |
Power dissipation |
Input voltage |
Output voltage |
Working frequency |
PF |
SMD LED quantity |
Color |
Brightness(lm) |
GPT806082x |
8W |
AC85-300V |
57V / 0.144A |
50-60HZ |
>95 |
144PCS |
Warm/pure/cool white |
792±10% |
Operating temperature |
Environment Humidity |
Pels (Ra) |
Short current |
Storage temperature |
Power dissipation for static state |
Tolerance for input constant current |
Noise |
|
0-55°C |
>65% |
63-84 |
<5mA |
-20--50°C |
<0.1W |
<3% |
<200mV |
T8 LED Tube Package:
Carton size: 713*240*240mm
Net weight per LED Tube: 182g
Net weight per carton: 4.75Kg
Gross weight per carton: 8.21Kg
Quantity per carton: 25PCS
LED Tube length: 602×φ26mm
Equal to: 20W traditional fluorescent lamp
T8 LED Tube:
