9W new retrofit LED tube
- 5000 Piece / Pieces per Month
- Xiamen
- T/T
- Radar Sensor T8 LED Light Tube 9W 12W 18W 22W
- 150cm LED lighting LED Tube Light Fluorescent Replace Led tri proof Lamp Fixture
- CBK Hot-Selling Car wash Tool LED panel light Lighting LED Lights for car care workshop
- CBK hot-selling car wash special lamp car beauty lamp repair shop ceiling lamp
- CBK In-store beauty station lamp honeycomb hot-selling car wash beauty shop lighting
- CBK hot sale square led wall lamp professional car wash auto beauty shop LED lamp
Product Details
LED Light Source: | 3528 SMD | Warranty(Years): | 3 | Input Voltage(V): | AC100-240V |
Lamp Power(W): | 9 | Lamp Luminous Flux(lm): | 980 | Lamp Luminous Efficiency(lm/w): | 109 |
Working Temperature(℃): | -20, 40 | Working Lifetime(Hour): | 50000 | Lamp Body Material: | PVC |
IP Rating: | IP44 | Certification: | CE | Place of Origin: | Fujian, China |
Brand Name: | GOPRO | Model Number: | Other, T8, GPT80608XX |
Product Description
Specifications
9W Tube T8,1) 792+-10%
2) 144pcs white led, 6500k
3) CE & RoHs certificate
4) Lifespan 30000hrs
8W T8 led tube lights
T8 LED Tube Features:
- LED tube adopt the latest LED technology, which can save 70% power consumption.
- LED as the third generation Semiconductor lighting contain
- many advantages as below:
(1) High luminous efficiency: 80%-90%.
(2) High luminous quality: none thermal, none EMI.
(3) Low power consumption: single LED between 0.05W to 1W, which is 1/8-10
compared to normal Incandescent.
(4) Lifespan: 30,000hours under 30% brightness fading.
(5) Appearance specification: small and various size, flat package, which can apply to dot, line, surface application.
(6) Driver: 1.5-2V/ 20-85mA
(7) CE& RoHS compliance/recycle
(8) Fast response: available for high frequency operation.
T8 LED Tube Specifications:
Item | Power | Part No. | LED Qty. | Dimension(mm) | Weight (pc/g) | Color Temperature | Package Size(cm) | Qty/box | Input Voltage (V) | Power Factor | Luminous Flux (LM) | |
DIA. | Length | (K) | ||||||||||
1 | 9w | GPT806092x | 144 | 26 | 602 | 190 | 2700-10000 | 713*240*240 | 25 | AC85-300v | >95 | 792±10% |
2 | 15W | GPT812152x | 276 | 26 | 1212 | 350 | 2700-10000 | 1335*240*240 | 25 | AC85-300v | >95 | 1518±10% |
3 | 12w | GPT809122x | 189 | 26 | 906 | 260 | 2700-10000 | 935*240*240 | 25 | AC85-300v | >95 | 850±10% |
3 | 25W | GPT815252x | 432 | 26 | 1512 | 450 | 2700-10000 | 1635*240*240 | 25 | AC85-300v | >95 | 2376±10% |
8W T8 LED Tube:
Part no. | Power dissipation | Input voltage | Output voltage | Working frequency | PF | SMD LED quantity | Color | Brightness(lm) |
GPT806082x | 8W | AC85-300V | 57V / 0.144A | 50-60HZ | >95 | 144PCS | Warm/pure/cool white | 792±10% |
Operating temperature | Environment Humidity | Pels (Ra) | Short current | Storage temperature | Power dissipation for static state | Tolerance for input constant current | Noise | |
0-55°C | >65% | 63-84 | <5mA | -20--50°C | <0.1W | <3% | <200mV |
T8 LED Tube Package:
Carton size: 713*240*240mm
Net weight per LED Tube: 182g
Net weight per carton: 4.75Kg
Gross weight per carton: 8.21Kg
Quantity per carton: 25PCS
LED Tube length: 602×φ26mm
Equal to: 20W traditional fluorescent lamp
T8 LED Tube:
