Car Led Light Strip 335

Car Led Light Strip 335 thumbnail-1
Car Led Light Strip 335 photo-1
Negotiable MOQ: 1 Meter (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Fujian, China
Brand Name:
GoPRO
Model Number:
GP-5050FXWP30-12
Contact Supplier Request Quote Chat Now
Xiamen Guangpu Electronics Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Xiamen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Fujian, China
Brand Name GoPRO
Model Number GP-5050FXWP30-12

Specifications

Car Led Light Strip 335
1.high brightness
2.CE&RoHS&UL approved
3.fast delivery
petitive price

Car Led Light Strip 335



Electrical/Optical Characteristics




Part No


Color


Operating
Voltage


LED‘Q



Length


LED spacing


Wavelength
/TC

Luminous flux(lm)/m

GP-5050FXWP30-12



Red



12DC





60





5m





16.7mm



620-625

80-100

Green

518-525

120-150

Blue

465-470

25-35



Maximum power per meter

14.4W

Maximum current per meter

1.2A

Maximum power per roll



72W

Maximum current per roll

6A


light source

5050RGB


operating  humidity

30%~85%

PCB thickness



0.25mm


Led quantity

3


PCB material

polyimide


Maximum connection length

5m


PCB color

White/black/yellow


power connection mode

Wire or SM-4P wire


luminescence angle

120


Package Type

Lectrostatic prevention package


luminescence decay

Less than 15%(10,000Hs)


product weight

0.22kg


life span



50,000Hs


waterproof measures

Silicone tube


storage temperature

-40°C~80°C


IP grade

IP67


operating  temperature

-30°C~60°C


Safety Certification

UL/CE/ROHS



 product demensions

Car Led Light Strip 335



RGB strip installation

1.5m strip connection method: connect the strip to controller and then connect the controller to power supply, so can light the strip, as shown in figure.

 Car Led Light Strip 335



2.  10m strip connection method, connect the two strips to controller and then connect the controller to power supply, so can light the strip, as shown in figure

 Car Led Light Strip 335



3. Several strips connection method: firstly connect the first strip to controller and connect the controller to power supply. Then connect the other end of the strip to the output side of the relay amplifier, so the strip can be connected to the power supply through relay amplifier, and the input side of the relay amplifier can be connected with the next strip whose the other end is connected with the input side of the second relay amplifier, and the second relay amplifier is connected with the power supply, By this way, one controller can control sever strips. As shown in figure.

Car Led Light Strip 335
