ROMAI electric bike,electric bicycle,electric scooter,electric vehicles,e-bike,e-scooter,two wheeler,battery operated bicycle
Shanghai Houlong Electronics Co,.Ltd.
Brand name:Romai
Item NO.: TDR110Z
350W 48V controller:
Voltage:48v
Rated power :350w
Maximum Power:600w
Maximum Current :17A
Mosfet :pieces
350W 48V brushless hub motor:
Size: 16*2.125
Output power: 350W
Rated current: 6.5A
Rated speed: 376r/min
Rated torque: 10.6N.m
Insulation class: E
weight:5.6kg
48V 12Ah Lead-acid battery:
| Battery Model | Voltge/Capacity | Weight | Size(L*W*H) | |
| 6-DZM-12 | 12V 12Ah | 4.3kg | 151±1mm*99±1mm*97±1mm | |
| 6-DZM-20 | 12V 20Ah | 7.1kg | 181±1mm*77±1mm*170±1mm | |
| 6-DZM-28 | 12V 28Ah | 11.0kg | 196±2mm*130±1mm*154±2mm | |
Product specifications:
1.Product Size(L*W*H): 1530*310*1100 mm
2.Wheelbase: 1170mm
3.Mini Ground Clearance: 170mm
4.Front Brake:Drum Brake
Rear Brake: Drum Brake
5.Max Loading Capacity: 75kg
6.Driving Distance Charge:Max 60km
7.Packing Size(L*W*H):1280*380*650 mm
8.Front tire: 14"*2.125
Rear tire: 14"*2.125
Lead-acid Battery:
| Battery Model | Voltge/Capacity | Weight | Size(L*W*H) | |
| 6-DZM-12 | 12V 12Ah | 4.3kg | 151±1mm*99±1mm*97±1mm | |
| 6-DZM-20 | 12V 20Ah | 7.1kg | 181±1mm*77±1mm*170±1mm | |
| 6-DZM-28 | 12V 28Ah | 11.0kg | 196±2mm*130±1mm*154±2mm | |
Note:
1.Delivery time: 20 days after receiving the deposit.
2.MOQ : one 20"FCL container;
3.Delivery Term: FOB Shanghai
4.Warranty :The key parts is 1 year after the shipping date on B/L.
5.Payment Term: 30% Down payment, 70%T/T before delivery.
6.Validity: 30 days from offer date.
Established in 2001,Shanghai Houlong Electronics Co.,Ltd is a professional manufacturer of e-bikes.e-tricycles and spare parts,contributing his power in foreign trades and gain very good achievements.As a subsidiary of Shanghai Minyuan(Group)Company,with strong back from brother company Puyang Romai Electric Vehicles Co.,Ltd.,Houlong has did excellent job in e-vehicles exporting.Products branded by Romai cover e-bikes.e-tricycles and spare parts.which are all manufactured by exclusive factory in Henan Province.With well-trained staff and advanced manufacturing equipment,the annual output reached to millions.
Romai E-vehicles have been exported to Europe,America,Middle Asia,Southeast Asia and more than twenty countries in the during years.
What we serve and what we feature:
Efficient order processing
Quick inquiry response
Multi payment terms
Punctual delivery
Multi ports choices
Good credit
Packing&delivery:
Product show:
1. Q: Can I get some samples?
A: Yes, sample order is available for quality check and market test.
2. Q: What’s the delivery time?
A: It takes 30 days for production based on specifications for your order and quantity.
3. Q:What's your payment terms?
A: We usually accept T/T as the main payment terms, and other payment are negotiable.
4. Q:What's your warranty terms?
A: Different components have different warranty, but for wholesale business, we can offer a certain percent easily damaged parts for free.
5. Q: Do you have the products in stock?
A: Sorry we don't have stock, we obey BTO (make to order). Sample order can be faster.
6. Q: How does your factory do quality control?
A: Quality is priority. Our professional staff will do quality control. Also each product will be fully assembled and carefully tested before packing and shipping.
