Help Center360 Degree Rotate Mini Size Outdoor Thermal PTZ Camera
Related Products
-
5 Kilometer Detection IP Thermal Image CameraUS$ 2,000 - 3,000MOQ: 1 Unit -
Gyro-stabilized Marine Thermal CameraUS$ 1,000 - 1,500MOQ: 1 Set
-
2016 Cheap China Price Thermal Imaging CameraUS$ 1,000 - 1,200MOQ: 1 Unit
-
Ip66 Outdoor Car Mounted Mini Thermal CameraUS$ 1 - 1,000MOQ: 1 Set
-
360 Degree Rotation Outdoor Thermal PTZ CameraUS$ 1 - 100MOQ: 1 Set
Thermal Camera Designed for Car / Vehicle / Military Tank etc mobile applications.
Mini Thermal PTZ Camera
XT-SH22-T
Features
1. Using the world’s most advanced FLIR uncooled VOx infrared focal plane array(FPA) with 320×240 pixels;
2.) Affords outstanding image quality and thermal sensitivity that can detect temperature difference less than or equal to 45mK at f/1.0
3.) With a detection range over 1.6km & 2.1km, the device is able to generate well-defined images in full darkness, haze and smog;
4.) The infrared thermal imager and the camera perform around-the-clock monitoring through video switch. The built-in heater ensures the display can show perfect monitoring images even in chilly and extremely harsh environments;
5.) Super strong protection for its critical parts meets the standard of US military Mil-Std-810 and IP66,.which is Moisture-resistant and waterproof, both components work well within the temperature range -32°C~+55°C;
7.) OSD function (English/Chinese)
8.) Clock wake-up function with various time-set tasks available.(Presets,Auto-scan,self-study,tracks etc.)
9.) 4 pattern tours (each one can record 200s)
10.) 6 cruising tracks and 128 preset positions;
11.) Power input for general monitoring purposes: AC 24V/2.5A or DC12V for Marine & vehicles
Parameter
Model |
XT-SH22-T-3225 |
XT-SH22-T-3219 |
Sensor Type |
Uncooled LWIR Thermal Imager,VOx Microbolometer |
|
Sensor Format |
320x240 pixels |
320x240 pixels |
Spectral Band |
7.5 ~ 13.5μm |
|
Field of View |
28°(H) ×23°(V),25mm lens |
36°(H) ×27°(V),19mm lens |
IFoV2 (milliradians) |
1.5 mrad(25mm lens) |
2 mrad(19mm lens), |
range performance |
About 2.1km (detection Distance) |
About 1.6km (Detection Distance) |
About 650 (recognition Distance) |
About 390m(Recognition Distance) |
|
NEdT Performance |
< 45 mK at F=1.0 |
|
Analog Video |
9Hz (PAL) |
|
Focus |
Factory-set at infinity focus; lens thread mount allows focus adjustment |
|
Digit Zoom |
4× |
|
Image processing |
Digital Detail Enhancement (DDE). |
|
Mechanism Parameter
Pan range |
360° |
Tilt range |
-25°~+90° |
Pan speed |
0~60°/s |
Tilt Speed |
0~40°/s |
Pan preset speed |
80°/s |
Tilt Preset speed |
60°/s |
Preset/track |
128 preset,6 cruising tracks |
Communication |
Multi-protocol,Baud Rate from 2400bps to 19200bps for optical,RS485 control |
Auto pan speed |
0.5~30°/s |
pattern tour |
Four pattern tours ,each one can record 200s |
4 Alarm in |
Normal open, when closed alarm |
1 Alarm out |
NC/NO output |
Power supply |
AC24V±10% |
Power consumption |
50VA |
Weight |
2.5Kg |
Amount |
Horizontal Base Installation |
Relative humidity |
10-90%RH |
Work temperature |
-35°C~55°C |
IP grade |
IP66 |
