Help CenterZmodo Indoor IR 650TVL Dsp Color CCD Camera
Related Products
-
Zmodo Sony CCD Waterproof 650TVL Effio CCTV CameraNegotiableMOQ: 50 Pieces -
Zmodo Sony CCD 22x Zoom Camera Outdoor Pan TiltNegotiableMOQ: 50 Pieces
-
Zmodo Indoor Infrared Sony CCD Video CameraNegotiableMOQ: 50 Pieces
-
Zmodo IR Waterproof 650TVL Extreme hd CameraNegotiableMOQ: 50 Pieces
-
Zmodo Indoor IR PTZ Sony CCD Board CameraNegotiableMOQ: 50 Pieces
Specifications
* 1/3" Color Sony CCD IR dome camera* Up to 65' IR Night Vision w/ 22LEDs
* 14F~122F operation condition
* One Year Warranty
Built-in Audio & 1/3" SONY "Effio-E" Color CCD Sensor 650TVL & 3.6mm Fixed lens & 65ft IR Night Vision & Indoor Use
This super high resolution vandal and weatherproof camera delivers clear, high-quality video and audio with 650TVL and 1/3" SONY Color CCD. 22 IR LEDs allow for 65ft of automatic night vision. You can view much wider field of view with the built-in 3.6 mm fixed lens With this high performance camera you can feel secure in knowing you picked a top of the line camera that will never miss a thing when monitoring your property.
650TVL High Resolution, Super Clear & Crisp Image with True Color
The high quality 1/3" Sony CCD image sensor in this camera provides a clear, crisp and consistent picture at 420TV lines of resolution without any color variation.
Up to 65FT Night Vision
22 infrared (IR) LEDs activate automatically in low-light or no-light situations to allow you to see up to 65’ away, and deactivate once lighting conditions are brighter.
See More with Wide Viewing Angle
See more area with the wide 70 degree viewing angle on the 3.6mm lens Cameras. Protect larger areas such as driveways, entrances, warehouses, large retail stores, parking lots, front and backyards.
Super Clear Dome Housing
Two layers of protective casing outside the lens optimize the light transmission and fastness of the cover, perfect for indoor monitoring.
Ceiling or Wall Mounting
You can mount it at ceiling or on the wall at any positions conspicuous or inconspicuous for the perfect viewing angle, either 360 degree horizontal or 90 degree vertical.
Durable Cable Plug with Low Impedance
The low impedance video power cable plug is designed to be last for long time use. BNC and RCA connections are used for video and power. It is easy to install hassles free and just plug and play.
Easy OSD Menu Control
The mini controlling joystick is designed on the video power port connection cable. Via it, you can move this joystick up and down, to travel from different functions icons on the menu to control color settings., and press the control button to confirm. It’s so compact and simple
Built-in Audio
This camera can capture different voices to help indentify object even though the light is not enough to capture the face detail.
Auto Iris
Auto Iris Lenses have built in motors to control the amount of light that reaches the imaging sensor. Auto Iris lenses are generally used in outdoor applications where lighting levels are not consistent, and or where shutter speed changes are not acceptable. DC Driven lenses are most common in the CCTV industry.
Auto White Balance
This is a function that influences representation by the camera all the colors, in reference to "white" color. In automatic mode, the reference point for white is the brightest point in the image.
Auto Back Light Compensation
Backlight compensation is video gain done either manually or automatically to correct the exposure of subjects that are in front of a bright light source.
| Model | ZMD-CDH-DGM23NA- High Reso Dome Camera |
| Image Sensor | 1/3" Sony Color CCD |
| Horizontal Resolution | 650 TV-Lines |
| TV System | NTSC / PAL |
| Effective Pixels | NTSC: 976 (H) x 494 (V) / PAL: 976 (H) x 582 (V) |
| Lens Mount | 3.6mm |
| Scanning System | 2:1 Interlace |
| Infrared Irradiation Distance | 22 Ultra Strong Infrared LEDs- Visible up to 65ft (20-25m) |
| Minimum Illumination | 0 Lux (IR On) |
| Synchronization System | Internal Synchronization |
| S/N Ratio | > 48dB |
| Audio | Built in |
| Gamma | 0.45 |
| Auto Gain Control | Built in |
| Power | 12V DC |
| Operation Temperature | 14°F ~ 122°F |
| Back Light Compensation | Auto |
| Video Out | 1.0V p-p 75O BNC |
| Auto Iris | Video / DC |
| Dimensions | 5" x 5" x 3.6" |
| Weight | 0.12lbs |
