FAW Truck Crane 4X2 truck crane capacity 8 ton heavy duty crane truck
FAW Truck Crane 4X2 truck crane capacity 8 ton heavy duty crane truck
can be used for common cargo truck with dumping device, also can be used for lifting. The truck is convenient for use with easy operation and long service life.
The truck consist of truck chassis, cargo box, hydraulic oil tank, crane, hydraulic oil pipe, operation platform and can be designed according to customer.
FAW Truck Crane 4X2 truck crane heavy duty crane truck 8 ton truck crane truck XCMG crane 180hp cargo truck with crane reference Technical information as following:
Basic information
Overall size: 8995*2495*3500 mm,
Cargo box: 5400*2300*600 mm,
Wheelbase: 4800/5300 mm,
F/R suspension: 1400/2295 mm,
F/R Track: 1800/1800mm
GVW: 15795kgs,
Curb Weight: 9400kgs,
A/D angle: 18/10,
Max speed: 96km/h
Drive: 4x2, left hand drive, power steering
Brake: air brake
Engine
Model: BF6M2012-18E3, FAW
Power: 180hp,
Displacement: 6060ml,
Emission: Euro 3
Crane information
Max lifting weight/ |
8000/kg |
Lifting moment |
20t.m |
Crane type |
hydraulic, synchronous stretch |
Arm level |
four |
Crane arm travel time |
30/15S |
Viberation |
0-75° |
Front leg gap |
5.6m |
Rear leg gap |
4.8m |
Max lifting height |
16.1m |
Max working range |
14m |
Hydraulic system pressure |
28Mpa |
Oil tank |
180L |
Self weight |
3500kg |
Oil max flow |
1320mm |
Rotation angle |
360° |
Chengli special automobile Co., Ltd is an automobile manufacturer , the company is a marketing enterprise of various heavy automobile brands, integrating international and domestic trade. Besides, the company has established a good relationship with domestic and overseas customers from Africa, South America, the Middle East and South Asia, winning a universal recognition and trust from the oversea customers and contributing to China trucks’ entrance to the international market.
1.Quality control: our company truck pass ISO,CCC,BV certification.
2.Design capacity :Our factory have over 200 technicians and designers.
3. Exhibition: our factory attend Canton Fair every year.
4. Export market: Africa, Southeast Asia, Central Asia, South America , Oceania and so on.
5.Our company cooperate with famous chassis manufacturers, such as DONGFENG, FAW, SHINOTRUK, FOTON, and etc.
Scene of Company
Our business partners.
More options for FAW Truck Crane 4X2 truck crane heavy duty crane truck 8 ton truck crane truck XCMG crane 180hp cargo truck with crane
Products exhibition.
Export
Our customers.
More products
1. Fuel tanker truck, Oil Truck, Tanker Truck
2. Fire engine truck
3. Dump truck, tipper, heavy duty truck
We provide after-sales service for FAW Truck Crane 4X2 truck crane heavy duty crane truck 8 ton truck crane truck XCMG crane 180hp cargo truck with crane.
