Specifications
1. DP-HXP20 polyurea spray machine , two components polyurea spray system2. mixing ratio: 1:1
3. power: 3-ph 380v 50hz 45A
4
DP-HXP20 Polyurea Spray Machine , two components Polyurea Spray System
* DP-HXP20 polyurea spray machine is hydraulic powered system with best performance, stronger power, higher pressure and higher volume output.
* This HXP20 polyurea spray machine is designed for 1:1 or 1:2 polyurea spraying ( or polyurethane spraying). This is always your 1# choice if you want to take a professional machine for professional polyurea spraying jobs.
* Accurate temperature control and easy monitoring for result in good quality of spraying polyurea material
* Easy operating, easy cleaning, easy moving, high productivity polyurea sprayer machine.
* Strong power hydraulic motor could be used for your tough and professional spraying jobs with stable performance.
* The pressure could be adjusted from 120 to 240bar.
* The output volume could be adjusted from 4 to 9kgs per minute.
* User friendly machine’s control board which indicate all the data of the heating temperature, pressure, and digital volume meter for easy monitoring of the A+B two components volume.
Specification :
Model No: DP-HXP20
Mode of driving: Hydraulic
Mixing volumetric ratio:1:1 (or 1:2)
Maximum output volume:9kgs/min (20 lbs/min)
Real Air consumption: 0.4CBM/MIN
air compressor output: 0.6CBM/min
Spraying materials: about 150 square meters per hour
Maximum temperature:90°C (194°F)
Working temperature: 70-75°C
Maximum pressure:240bar / 3490psi
Working pressure: 180-200bar / 2600-2900psi
Heater power: 11 – 15kw
Maximum hose length: 90m
Power: 3-phase 380V 50Hz 45A
Net weight: 150kgs
Overall size: 85cm x 88cm x 110cm
Packing dimension: 70cm x 80cm x 125cm
Contents in package:
Machine 1 set, Transfer pump 2 sets, Heating hose 15m (50ft) 1000watt, Heating whip hose 1.5m (5ft), Polyurea spray gun 1 set, Repair kit 1 set, Cleaning fluid 1 kgDOP 1 kg
