DP-6880 Heavy-duty Putty Plaster Airless Sprayer

Specifications

DP-6880 Heavy-duty Putty Plaster Airless Sprayer
Motor power: 4HP 3000W 3-phase
Max. flow rate: 8L/min
Max. pressure: 25Mpa

  DP-6880 Heavy-duty Putty Plaster Airless Sprayer





DP-6880 Heavy-duty Putty Sprayer (8L/min 4HP) is especially designed for spraying white cement, putty, plastering, inorganic zinc coating and epoxy zinc-rich primer.

Technical specifications:
Motor power: 4HP 3000W 3-phase, 380V/ 50HZ
Max. flow rate: 8L/min
Max. pressure: 25Mpa / 250bar / 3625psi
Max. tip size: 0.041″ with 120bar spraying pressure
Length of standard hose: 12m
Max. length of hose: 90M
Size of stand nozzle: 70B25 (7L/min) for putty+ 40B25(4L/min) for paint
N.W./G.W.: 75KGS/ 85KGS
Dimension: 56x67x79CM

* Equipped with 3 phase asynchronous motor, low round speed but very strong power.
*Long-life chromate treatment Piston Rod, Sleeve, oversized Packings(Total 16pcs.).  For heavy duty spraying jobs.
*Build-in tool box for easy store up of the frequently-used tools and spare parts like tip, packing, filter etc.

Equipped with delta connection frequency converter and Features as below:
1. Saves more than 50% power
2. Motor soft start and stop, stabilization, less impaction, NO temperature rise even after 8 hours working.
3. Motor speed adopts frequency conversion control according to the size of the tip & the viscosity of the paint.
