Home > Electrical & Electronics > Electronic Tube & Transistor > Rectifier Diode > Factory Price Red and White Bi-Color Common Cathode 5630 Smd Led

Factory Price Red and White Bi-Color Common Cathode 5630 Smd Led

Factory Price Red and White Bi-Color Common Cathode 5630 Smd Led thumbnail-3

Factory Price Red and White Bi-Color Common Cathode 5630 Smd Led photo-1

Factory Price Red and White Bi-Color Common Cathode 5630 Smd Led photo-2

Factory Price Red and White Bi-Color Common Cathode 5630 Smd Led photo-3

US$ 0.1 - 0.5 MOQ: 3000 Pieces

Key Specifications

Get Latest Price

Place of Origin:

Guangdong, China

Brand Name:

Model Number:

CH-5630RW

Contact Supplier Request Quote Chat Now

Shenzhen Chunhui Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Guangdong, China

Brand Name CH

Model Number CH-5630RW

Type LED

Package Type Surface Mount

Max. Forward Voltage .

Max. Reverse Voltage 5.0V

Max. Forward Current 150mA

Factory Price red and white Bi-Color common cathode 5630 smd led

Product Description

1.Features

5630 SMD LED Bi-Color Red&white Common Cathode
5630 SMD LED Bi-Color Red&white Common Cathode
color	LM	(nm)CCT	Current	voltage
red	15-20	620-625nm	150Ma	2.0-2.4V
white	50-55	6000-6500k	150Ma	3.0-3.4V

1. Extremely wide viewing angle

2. Suitable for all SMT assembly and solder process

3. Available on tape and reel

4. Moisture sensitivity level: Level

5. Package:1000pcs/reel

6. RoHS compliant

2.Advantage:

High intensity, good consistency, low decay .

Available in various colors and view angle

Meet the RoHS and other environmental certification

3.Application:

1. Optical indicator

2. Indoor display

3. Interior automotive lighting

4. Backlight for LCD, switch and Symbol, display

5. Light pipe application 6. General us

What we have now:

1. 1w/3w high power led

2. 5w-500w high power led

3. 0.2w/1w smd 5050 led

4. 0.5w smd 5630 led

5. 0.1w 3014 led

6. 1w-300w UV/ IR led: 365nm, 395nm, 660nm, 730nm, 850nm and 940nm

7. RGB leds and colorful leds: Red, Green, Blue and Yellow

8. 10000-30000k led for fish tank

9. Special color led: Amber color led, Pink color led

10. High CRI led>80%

Packaging & Shipping

Shipping

1. FedEx/DHL/UPS/TNT for samples, Door-to-Door;

2. By Air or by Sea for batch goods, for FCL; Airport/ Port receiving;

3. Customers specifying freight forwarders or negotiable shipping methods!

4. Delivery Time: 3-7 days for samples; 5-25 days for batch goods.

Payment Terms

1. T/T (Wire Transfer)

2. WESTERN UNION

3. PAYPAL

4. ESCROW

Our Services

1.We are Alibaba Assessed 3 years Gold Supplier.

2.We are a factory manufacturing ,best production capability ,best quality control, Best Service .

3.Over 16000 suppliers around the world

4.100% QC inspection Before Shippment.

5. 24H favourable after-sale service .

FAQ

FAQ:

1. Prices conditions

The payment can be T/T transaction,Western Union,Paypal,Trade Assurance.

2. What will be the delivery time and what will be the mode of payment ?

We have large quantities in Stock for normal color,Normal size ,for special color and products sizes it need to 3-5 days to customize.50K units is available for most of our models in normal color and sizes

3.What’s the warranty terms for the products?

For every product sold, we support 12 months manufacturer’s limited Warranty. Accessories come with 3 months warranty.

4. Could you please send me the sample for the same . So that i could see and analyze its quality?

Yes. We can send samples first, samples need to be charged if the value is higher.

5.How much will the express delivery cost?

The shipping discount are different because of different weight, volume and destination, we will choose the cheapest and safest way according to your detailed requirement. For the exact cost, please contact us freely.

6.How soon will my order shipped?

Generally, upon the receipt of payment, goods will be shipped out within 2 working days for samples. (Note: Exact delivery time mainly depends on the carrier services.)

7.How much will the express delivery cost?

8. What can I do if I received a faulty item?

We hope all our customers will receive top quality goods. If you think there is a fault with an item when received, you can return it back to us. If any product is unsatisfactory, due to defective workmanship or materials, we will replace or refund you the purchase price if it meets our requirements.
