50w 3600 Lumen h7 Led Headlight / High Power Led Headlight Bulb h7 h4

Name: 50w 3600 Lumen h7 Led Headlight / High Power Led Headlight Bulb h7 h4
Brand: EK,OEM brand
SKU: 125236175
Availability: InStock

US$ 1 - 50 MOQ: 10 Sets

Key Specifications

Type:

Headlight

Voltage:

Other, 12V/24V

Lamp Type:

HID Xenon

Guangzhou EKLIGHT Electronic Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Guangzhou

Delivery Detail:

Delivery time depends on order quantity.

Type Headlight

Voltage Other, 12V/24V

Lamp Type HID Xenon

Certification CE,ROHS,TUV,ISO9001

Car Make all cars

Place of Origin Guangdong, China

Brand Name EK,OEM brand

Model Number led auto headlight

Warranty 2 Years

50w 3600 lumen h7 led headlight / high power led headlight bulb h7 h4

Parameters:

Item	Single beam	Dual beam	Special beam
Bulb type:	H7,H8,H10,H9/H11/H16(JP),H16(EU)/5202,9005,9006,H12,D1/2/3/4	H4,9004,9007,H13	H1,H3 available
Voltage:	9-32V	9-32V	9-32V
Lumen:	3800lm	3800lm/3800lm	3800lm
Protection Function:	nonpolarity	nonpolarity	nonpolarity
Anti-electromagnetic interference:	S95/54/EC	S95/54/EC	S95/54/EC
Output Power	22W	22W	22W
Work Temperature	-45℃~+85℃	-45℃~+85℃	-45℃~+85℃
Input Current	2A/13.5V	2A/13.5V	2A/13.5V
Color Temperature	2200K~6500K optional	2200K~6500K optional	2200K~6500K optional
Output short circuit protection	yes	yes	Yes

Features:

Ultra-light effect, ultra-low thermal resistance,exceeded Energy Star standards.
Light body heat dissipation all in one design, 360degree heat groove: Double-sided copper PCB board+ High thermal conductivity aluminum+ Copper mesh cooling,perfect thermal design.
Applied with newest copper mesh thermal system, with powerful thermal and heat dissipation, had solved overheat burning problem of LED headlight that caused by fan malfunction.
Copper mesh requires smaller space,optionally bent in different directions, coupled withsmall size cooling pad, suitable for all car types.
Quick start, reach 100% brightness when start up, with incomparable start response rate than HID.
Stationary base separate from light body design, easy to install,with removable stationary base adaptors, it can be changed to different base for separate use, lower the stock pressure.
Ultra small size driver design, connected with light source, easy for installation.
Complied with IP65 waterproof and dustproof standards(Don’t put lamp beads emitting surface into the water, because LED is directly exposed.)
In line with EMI anti-interference requirements, external canbus relay can pass the car computer system
