oil resistant high pressure steel wire spiral hydraulic hose
Description:
| material | NBR-Plastic alloys |
| color | black |
| surface | cloth |
| temperature | -40℃ ~+100℃ |
| certification | ISO9001,ISO14001,OHSAS18001 |
| inner tube | oil resistant |
| hose standard | EN,GB,SAE,DIN |
| inner diameter | 3/16~5 inch |
| sample | free sample |
| business type | manufacture |
| roll | 40 meters/100 meters |
| minimum order quantity | 50 meters |
| package | in plastic bag |
| delivery | within 2 weeks, or according to quantity |
| payment | L/C,T/T |
Product show:
| size | size | ID(MM) | W.D(MM) | Thickness(outer rubber ) | Max W.P | P.P | Min B.P | W.T | |||
| MM | INCH | min | max | min | max | min | max | (MPa) | (MPa) | (MPa) | kg/m |
| 4 | 1/4 | 6.2 | 7.0 | 12.4 | 14.5 | 0.8 | 1.5 | 35 | 70 | 140 | 0.30 |
| 5 | 5/16 | 7.7 | 8.5 | 13.3 | 15.7 | 0.8 | 1.5 | 29.7 | 59.5 | 119 | 0.34 |
| 6 | 3/8 | 9.3 | 10.1 | 15.9 | 18.8 | 0.8 | 1.5 | 28 | 56 | 112 | 0.42 |
| 8 | 1/2 | 12.3 | 13.5 | 19 | 22 | 0.8 | 1.5 | 24.5 | 49 | 98 | 0.54 |
| 10 | 5/8 | 15.5 | 16.7 | 22.5 | 25.4 | 0.8 | 1.5 | 21 | 42 | 84 | 0.68 |
| 12 | 3/4 | 18.6 | 19.8 | 26.3 | 29.0 | 0.8 | 1.5 | 42 | 42 | 84 | 0.80 |
| 16 | 1 | 25.0 | 26.4 | 34.0 | 36.6 | 0.8 | 1.5 | 14 | 28 | 56 | 1.15 |
| 20 | 1-1/4 | 31.4 | 33.0 | 41.9 | 44.3 | 1.0 | 1.5 | 11.3 | 22.7 | 45.5 | 1.83 |
Construction:
inner tube: oil resistant;
middle : four steel wire reinforced layers;
cover: oil and weather resistant.
Application:
used in mineral support, mechinery industy, used petroleum and water base hydraulic oil ,within a temperatuer -40~+100℃,and sometimes deliver many liquid,such as water, fuel oil and lubraction oil and ect.
