General Information
HARDWARE | |
CPU |
RockChip RK3066 Dual-core ARM Cortex-A9, up to 1.6GHz |
System RAM |
DDR3 1G |
System ROM |
NAND FLASH 4G |
Storage |
TF Card Slot (Up to 32G) |
Network |
LAN 10/100/1000Mbps, Internal Wi-Fi module 820.11 b/g/n, 3G Network |
OPERATING SYSTEM | |
O/S |
Android 4.2.2 (Jelly Bean) |
VIDEO PLAY | |
Support Format |
AVI (H.264, DiVX, XViD), RM, RMVB, MKV (H.264, DiVX, XViD), WMV, MOV, MP4 (H.264, MPEG, DiVX, XViD), DAT, VOB, PMP, MPEG, FLV (H.2634, H.264), ASF, TS, TP, 3GP, MPG…. |
Resolution |
Decoding Resolution 3840 X 2160 (Max.), Video Output : 1080P Full HD (Via. HDMI) |
AUDIO PLAY | |
Support Format |
MP3, MP2, WMA, OGG, AAC, M4A, MA4, FLAC, APE, 3GP and LRC |
PHOTO PLAY | |
Support Format |
JPG, BMP, PNG, GIF / Resolution 4096 X 4096 (Max.) |
CONNECTIONS | |
I/O |
1 x USB 2.0 Host, 1 x USB 2.0 OTG, 2 x UART, 1 x IR Port |
LVDS Interface |
1 x Single/Double LVDS Interface for TFT-LCD |
LCD Backlight |
1 x LCD Backlight Control Port |
Video In |
1 x HDMI, 1 x VGA Input |
Audio Out |
1 x Stereo Audio Out (2 x 5W/8Ω speaker can drive directly) |
Audio In |
1 x Stereo Audio Input |
Memory Card Slot |
1 x TF Card Slot |
Network |
1 x LAN Port (RJ45), 1 x Internal Wi-Fi module, 1 x Mini PCI-E Slot (for 3G Module, Not Include) 1 x Standard SIM Card Slot |
Power |
1 x DC Jack, 1 x Internal Power Port |
ELECTRICAL | |
PWR Input |
DC 12V (Power On/Off) |
PWR Consumption |
5W (without Speaker, LCD, Backlight Inverter, USB Device) |
Features
l Image, video, music, RSS, slide, interactivity, web, text are all supported.
l LOGO, instant messages, real-time date/time/week can be displayed.
l Support background image and background color.
l Support full screen and customized multi-zone presentation as you wish.
l Drag and drop editor makes content editing intuitive.
l Such slide features as IMP, music synchronization and background music are substitutes for the traditional light boxes and posters.
l The concise program publish interface allows you to arrange contents and their playback time, sequence, frequency and location easily.
l With intelligent scheduling, contents can be played on a loop, at a certain time or idle hours, or as instant break-ins.
l You can have your program published immediately or at your specified date and time.
l Contents can be updated remotely, or imported or read directly from a USB disk on site.
l Program previews and multi checks ensure information delivery correct and accurate.
l Owing to flexible classification management mechanism, players can be managed in organizations and groups, users can be granted different permissions.
l Advertiser details, related contents, price strategies and playback logs are all within your reach for ease of client management.
l Breakpoint resume, time download and bandwidth control help to make use of network resources more effectively.
l The powerful feature of time on/off in multiple periods achieves unattended operation.
l Player operations such as adjusting playback volume, changing display screen, reboot, and hibernation can be completed remotely with just one click.
l You are allowed to oversee players remotely in real time, and will be provided with various running and operation reports.
l Health monitoring technique is employed to give failure alert in time.
l Remote upgrade and intelligent DNS make operation and maintenance more convenient.
l Deployments across WAN/LAN/VPN/WiFi/3G network, and different regions are supported.
l Customizable for your specific needs and will easily scale as your business grows.
