DSHJ-5S Digital Viscometer
I.Introduction
1.DSHJ-5S Digital Viscometer adopts 16 bit microprocessor core control circuit, NO gear drive, RTD temperature probe real-time monitoring and measuring viscosity temperature, Blue screen LCD directly display viscosity, rotate speed, percentage torque, rotor number, and the biggest viscosity value of selected rotor in current rotate speed. Clear press button, stable rotate speed, precise measurement. Equipped with RTD temperature probe and RS232C standard output interface, you can store, contrast and record after connecting a PC. (PC interface is optional to realize full automatic data collection function).
2.Used in grease, paint, painting, medicine, food, cosmetics, adhesive and so on all kinds of liquid viscosity measurement, also can be used to measure viscous resistance and absolute viscosity of liquid.
II.Performance parameter
Model |
DSHJ-5S |
Measuring range(mPa·s) |
0~100,000 mPa·s (cP) |
Rotating speed(rpm) |
6, 12, 30, 60 |
Rotor |
5 types (L0-L4) |
Accuracy |
±1.0% |
Repeatability |
0.5% |
Power |
Power adaptor (input 220V 50±1Hz, output 15V 1.2A) |
Overall dimension & Weight |
280(length)*105(width)*258mm(height) ( Do not contain bracket),1.5Kg |
III.Configuration list
Main machine |
1 |
Seat leg,wrench |
1, 1 |
Power adaptor |
1 |
Certificate |
1 |
Rotor |
1 set |
Guarantee card |
1 |
Protection frame |
1 |
User manual |
1 |
Lifting frame |
1 |
Password package |
1 |
IV.Optional components
RTD temperature probe |
Small sample adapter |
Ultra low viscosity adapter |
Special heater |
Viscometer dedicated constant temperature water tank |
Teleoperator, printer |
