10G XFP Transceiver
10G 1310nm 10km XFP Transceiver Module Compatible ZTE XFP-10GE-S10K
XFP transceivers are designed for 10G Ethernet 10G 802.3ae and 10G SOI OC-192/SDH STM-64, and it supports data-rate from 9.953Gb/s to 11.1Gb/s. Digital diagnostics are available via I2C interface as specified in the XFP MSA. The transceiver are optimized for high performance and cost effective to supply customers the best solutions for datacom and telecom applications.
Features:
- 1310nm Laser diode transmitter
- Max distance up to 10km
- Protocol Agnostic: supports SONET OC-192/SDH STM-64, 10G Fibre Channel, G.709, and 10G Ethernet
- XFP MSA compliant
- OC192/STM-64 Eye mask compliant(6dB extinction ratio over temperature)
- Advanced Digital Diagnostics
- Monitor Device Temperature and Voltage
- Stable output power over temperature (low tracking error)
- Low power consumption
- 0 to 70℃ temperature range
- SIO Management Interface
- Die cast metal housing for low EMI
- RoHS compliant and Lead Free
Applications:
10Gbps Ethernet
SONET/SDH switches and routers
Digital video and Closedcircuit television(CCTV)
Other Optical Links
| HaiLi Part Number | Cisco Part Number |
Application | Data Rate | Wavelength | Distance | Connector Type |
| HL-XFP-SR | XFP-10G-MM-SR= |
XFP 10GB-SR | 10G | 850nm | 300m | LC |
| HL-XFP-LR | XFP-10GLR-OC192SR= | XFP 10GB-LR | 10G | 1310nm | 10km | LC |
| HL-XFP-ER | XFP-10GER-192IR+= | XFP 10GB-ER | 10G | 1550nm | 40km | LC |
| HL-XFP-ZR | XFP-10GZR-OC192LR= | XFP 10GB-ZR | 10G | 1550nm | 80km | LC |
| Order details | |||||
Min.Order Quantity: 1pcs is also okay for sample to satisfy your need.
OEM/ODM is acceptable, so tell us your requirements.
Compatible Brand: Cisco, Huawei, Ciena, H3C, HP, Extreme, Foundry, Brocade, D-link, Alcatel, Riverstone, Enterasys, Netgear, Nortel, Juniper, Ruijie, Zyxel, etc.
Shipment & Payment
International Express: DHL, Fedex, UPS, EMS, UPS, TNT and etc.
Payment: T/T, Western union, Paypal and so on.
| Sales Service | |||||
1.Contact our sales for more details to confirm your order.
2.Short lead time after confirmation.
3.We deliver goods by international Express.
4.Quick response for customers' feedback and other questions.
5.Guarantee:
›& Brand new.
›& OEM/ODM is available.
›& 100% through quality test and aging test.
›& 3 years for SFP, 1 year for Muxes warranty(From the date of shipment).
6.Technician support:
We support technical guide to solve malfunction or substitute components, and provide the project of related networking configuration.
7.After-sales service
We have after service for 24 hours, promises to supply technical service or guide in anytime.
Our co-workers will be response clients's requirement in 12 hours after emergency happened.
| Category |
| Package details | |||||
Packing Details: Static bag, Plastic PVC Pack, Retail box, Technical box, or customized.
Shenzhen Haili Link Technology Co., Ltd. which is specialized in manufacturing and marketing fiber optic products, was founded in 2007.
RoHS, ISO&CE cerificated, we are golden supplier which specializes in this field 10 years with superior quality, competitive price and good solution.
Our core competencies are fiber optics of CFP, QSFP28, QSFP SR4&LR4, CWDM SFP/XFP/X2, DWDM SFP/XFP/X2, solutions of DWDM, CWDM, WDM, MPO, AAWG, etc.
We have an independent Research&Development Department with 8 skillful engineers, with some advanced equipments and devices, such as cisco switch and routers, for further detailed test and procedure.
We also have related optical products and good solutions to satisfy customers' requirements.
Notes:
Here is one type product, pls contact me to get the modules that you are interested to purchase.
Send me an inquiry directly with your requirements or add my skype(hilink02) for further informations.
