Product Details
Place of Origin: | Guangdong, China | Brand Name: | HaiLi | Model Number: | CWDM X2 -XX |
Product Description
Fiber Optic Network 40Km Reach 10Gbps CWDM-X2-1590
CWDM-X2-1590
Features
Hot-pluggable X2 footprint
XAUI electrical interface: 4 lanes 3.125 GB
MDIO, DOM (Digital Optics Monitoring) support
850nm/1310nm/1550nm/DWDM laser transmitter
Power supply 5V/3.3V and adaptable power supply (APS: 1.2V)
PIN photo-detector
Duplex SC optical receptacle
Compliant with IEEE 802.3ae
Compliant with X2 MSA
Class 1 laser product complies with EN 60825
Compliant with RoHS
Operating Case Temperature:
Standard: 0C to 70C
Extended: -10C to +75C
Industrial: -30C to +85C
Application
Access networks : 10Gbps Ethernet or Sonet SDH switches and routers
Digital video and Closedcircuit television(CCTV)
Other 10Gbps optical links
CWDM PON network including 10G CWDM XFP/SFP+ 10g CWDM X2/XENPAK
10G CWDM Transceivers
CWDM XFP(10G) | |||||
CWDM XFP LR | 10G | (1270-1330nm) | 10KM | CWDM XFP | 0~70°c |
CWDM XFP ER | 10G | (1470-1610nm) | 40KM | CWDM XFP | 0~70°c |
CWDM XFP ZR | 10G | (1470-1610nm) | 80KM | CWDM XFP | 0~70°c |
CWDM SFP+(10G) | |||||
CWDM SFP+(10G) LR | 10G | (1270-1330nm) | 10KM | CWDM SFP+ | 0~70°c |
CWDM SFP ER | 10G | (1470-1610nm) | 40KM | CWDM SFP+ | 0~70°c |
CWDM SFP ZR | 10G | (1470-1610nm) | 80KM | CWDM SFP+ | 0~70°c |
CWDM XENPAK(10G) | |||||
CWDM XENPAK ER | 10G | 1470~1610 | 40KM | XENPAK | 0~70°c |
CWDM XENPAK ZR | 10G | 1470~1610 | 80KM | XENPAK | 0~70°c |
CWDM X2 (10G) | |||||
CWDM X2 -ERC | 10G | 1470~1610 | 40KM | X2 | 0~70°c |
CWDM X2-ZRC | 10G | 1470~1610 | 80KM | X2 | 0~70°c |
OEM and ODM
OEM/ODM order is available.
Shipment
International Express: DHL, FedEx,EMS,TNT, UPS and so on. It takes 3-7 days.
Guarantee
We promise all the advertised optical transceivers are brand new with new components and parts and absolutely never use old and refurbished materials. All the optical transceivers have been through functional test and aging test. We provide 3 years warranty for all the optical transceivers from the date of shipment.
What we supply
We supply all kinds of compatible optical transceiver modules, including SFP, GBIC, SFP+, XENPAK, X2 , XFP, BIDI,CWDM,DWDM and other special transceiver modules. Our products are compatible with Cisco, Ciena, H3C, HP, Extreme, Foundry, Avaya, D-link, Alcatel, Riverstone, Enterasys, Netgear, Nortel, Juniper, Ruijie, Zyxel, Huawei,etc.
- CWDM-X2-1590
Product picture show
As we have varies kinds of products,if you can't find the correct product you need,please send us an inquiry.We will reply shortly.
