3 portS Optical circulator
- 300 Piece / Pieces per Month
- shenzhen
- Credit Card PayPal
- ZTE 5928E, RS-5928E, RS-59EC-PWR-AC10, RS-59EC-PWR-DC10, 24 GE RJ45 + 1 expansion card ZTE ZXR10 5928E 5952E 5916E RS-5916E RS-
- ZTE 2952E, RS-2952E-AC, RS-2952E-DC, 48 FE RJ45 4 GE SFP ZTE ZXR10 2952E 2928E 2918E 2910E
- ZTE 3950-28TM, RS-3950-28TM-AC, 24 FE RJ45 + 2 GE SFP + 1 expansion card slot ZTE ZXR10 3950
- ZTE 2950-18TC, RS-2950-18TC-AC, 16 FE RJ45 + 2 GE Combo ZTE ZXR10 2950
- ZTE S2XF48A, 48-port 10GE SFP+ optical interface ZTE ZXR10 8902E 8905E 8908E 8912E RS-8902E RS-8905E RS-8908E RS-8912E
- ZTE 5250-28PM-H, RS-5250-28PM-H, 20 GE RJ45 (POE/POE+) + 4 GE Combo ports + 1 expansion card ZTE ZXR10 5250
Product Details
Place of Origin: | Guangdong, China | Brand Name: | Haili | Model Number: | HL-FOC13-xxC |
Product Description
3 Port Polarization Insensitive Optical circulator
Features
High Channel Isolation
Low Insertion Loss
High Return Loss
Low PDL
High Stability and Reliability
Compact in-Line Package
Epoxy Free Optical Patch
Application:
•Optical Fiber Amplifier
•Broadcast Communication
Optical Circulator Parameter:
Grade | GRADE P | GRADE A |
Construction | Port1 to Port 2, Port2 to Port3 | |
Operation Wavelength(nm) | 1310/1550/ 1585 | |
Standard Input Loss(23°C) | 0.6 | 0.8 |
Max. Insertion Loss(23°C) | 0.8 | 1 |
Max. Isolation(dB) | 50 | |
Min. Isolation(dB) | 40 | |
Directivity(dB) | 50 | |
PDL(dB) | 0.15 | |
PMD(ps) | 0.1 | |
RL(dB) | 50 | |
Bandwidth(nm) | +/-30 | |
Max. Operating Power(mw) | 500 | |
Operating Temperature(°C) | 0~70 | |
Storage Temperature(°C) | -40~85 | |
Dimension (mm) | Φ5.5xL50 or 90*20*9.5 |
