Single Mode 1x2 Fiber Optical Switch
Features
Unmatched Low Cost
Low insertion Loss
High Channel Isolation
High Stability, High Reliability
Epoxy-free on Optical Path
Latching or Non-latching
Applications
Optical Network
Protection/Restoration
Optical Singnal Routing
Configurable Optical Add/Drop
Transmitter and receiver protection
Network Test System
Specification Performance
|
Parameters
|
HL-1×2 |
||
Wavelength Range |
nm |
850 |
1260~1650 |
Operating Wavelength |
nm |
850 |
1310/1490/1550/1625/1650 |
Insertion Loss |
dB |
Typ:0.8 Max:1.2 |
Typ:0.5 Max:0.8 |
Return Loss |
dB |
SM≥50 |
|
Crosstalk |
dB |
SM≥55 |
|
PDL |
dB |
≤0.05 |
|
WDL |
dB |
≤0.25 |
|
TDL |
dB |
≤0.25 |
|
Repeatability |
dB |
≤±0.02 |
|
Power supply |
v |
3.0 or 5.0 |
|
Lifetime |
Time |
≥107 |
|
Switch Time |
ms |
≤8 |
|
Transmission Power |
mW |
≤500 |
|
OperatingTemperature |
°C |
-20~+70 |
|
Storage Temperature |
°C |
-40~+85 |
|
Min.Order Quantity: 1pcs is also okay for sample to satisfy your need.
OEM/ODM is acceptable, so tell us your requirements.
SFP compatible Brand: Cisco, Huawei, Ciena, H3C, HP, Extreme, Foundry, Brocade, D-link, Alcatel, Riverstone, Enterasys, Netgear, Nortel, Juniper, Ruijie, Zyxel, etc.
Shipment & Payment
1. International Express: DHL, Fedex, UPS, EMS, UPS, TNT and etc.
2. Payment: T/T, Western Union, Paypal and so on.
Sales Service:
1. Contact our sales for more details to confirm your order.
2. Short lead time after confirmation.
3. We deliver goods by international Express.
4. Quick response for customers' feedback and other questions.
5. Guarantee:
›& Brand new.
›& OEM/ODM is available.
›& 100% through quality test and aging test.
›& 3 years warranty (From the date of shipment).
6. Technician support:
We support technical guide to solve malfunction or substitute components, and provide the project of related networking configuration.
7. After-sales service
We have after service for 24 hours, promises to supply technical service or guide in anytime.
Our co-workers will be response clients's requirement in 12 hours after emergency happened.
Packing Details: Static bag, Plastic PVC Pack, Retail box, Technical box, or customized.
Notes:
Here is one type product, we also have CWDM/DWDM Mux/Demux Module, CWDM/DWDM/BiDi SFP, Xenpak/X2, FWDM and so on.
Send me an inquiry with your requirements directly or add my skype (hilink02) for further informations.
I am looking forward to your messages!
