HCC950 Series payment Pinpad with highly secure debit transaction
General
HCC 950 security pin pad delivers fully reliable and highly secure debit transaction,
connects easily with various terminals, also provides additional functions such as voice-hint module,LCD module and DES encryption module, serve as professional PIN input device for POS, banks, retail and securities markets.
Feature
Ÿ Equipped with highly secure PIN shield
Ÿ Support DUKPT or Master/Session key management
Ÿ Comply with international security standards and payment scheme specifications
Ÿ Compatible with kindred products such as IBM4778
Ÿ Applicable to many operating systems: UNIX, WINDOWS, NT and OS/2,etc.
Ÿ Easy-to-read LCD display
Ÿ Small table-top footprint to save counter space
Ÿ High-quality conductive rubber button
Ÿ Support different security key entry software
Ÿ Provide audio and visual key entry response
Ÿ Simple user-friendly operation
Ÿ Vandal resistant: self-destroyed against violence
Ÿ Can be further user-customized
Specification
Display |
2-line/16 characters alphanumeric or graphical LCD display |
Keypad |
15 keys, ergonomically designed, |
Communication interface |
RS232, standard keyboard, TTL connection, 300~19,200 bps at option, 1200BPS default, asynchronous |
Power supply |
DC 6-14V, 30mA maximum |
Connector |
DB9 or customize |
Security |
Software controlled DES & DUKPT key management |
Reliability |
> 5 x 106 times input (per each key) |
Working temperature |
0~40°C |
Humidity |
15%~85% RH non-condensing |
Dimensions (L*W*H) |
152mm*102*93mm |
Weight |
350g (include wiring) |
Housing |
Plastic PC, Ivory color |
Model Description 950x1-x2-x3-x4
Type |
X1 |
Interface |
X2 |
DES/3DES Module |
X3 |
LCD Module |
X4 |
Sound Module |
|
950 Pin Pad, with Conductive Rubber key |
R |
RS232 Series port |
0 |
No |
0 |
No |
0 |
No |
B |
PS/2 |
1 |
Yes |
1 |
Yes |
1 |
Yes |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
7 8 |
IBM 4778 Compatible |
|||||||
For example
HCC950 R 111 – Conductive Rubber key Pin pad, with RS232 series interface, DES/3DES encryption module, LCD module, Sound module. HCC950-78 – IBM 4778 Compatible
