high precision Sliding Table Panel Saw for sale
1. The Sliding Table Saw Types You Can Choose:
1). Max. adjustable angle of main saw blade and socring saw blade: 0-45º or 0º only.
2). Slide table guide rail type: round rod structure(Y) or linear structure(Z). width 375mm.
Optional: 415mm width, small or big european style with locking device
3). Saw blade lifting and tilting system (manual):
Optional: digital display.
4). Sliding table length from 1500mm to 3800mm (usually we have 1600, 2200, 2600, 2800, 3000, 3200, 3800mm).
5). Accessories:
(1)Pressure Utensil
(2) Push Handle
(3) Angle Ruler
(4). Protection hood
Optional: Big Protection Hood
2. Advantages:
All the sliding table saws have ISO certification and we have passed the Chinese export commodity inspection.
3. Main technical parameter
Dimensions sliding table |
3200×375mm |
Gross cut capacity |
3200mm |
Width of cut between saw blade and rip fence |
1250mm |
Saw blade φ |
φ300mmφ250-φ300 |
Height of cut φ300mm |
80mm |
Height of cut with saw blade φ300mm at 45° |
55mm |
Speed of main saw blade |
4000/6000rpm |
Spindle diameter |
φ30mm |
Tilling saw blade |
0-45° |
Main motor |
5.5kw |
Scoring saw blade |
120mm |
Speed of scoring saw blade |
8000r/min |
Spindle of scoring saw |
20mm |
Motor |
1.1kw |
Net weight |
780kg |
Gross weight (wooden packing case) |
880kg |
Overall dimensions |
3200×3150×900mm |
Auxiliary table 1 |
745*545mm |
| Auxiliary table 2 | 745*755mm |
| Fixed cast iron table | 1000*570mm |
4. Apprearances and colors can be customerized
(1) Pre-sale services:
* Provide the free consultation of the equipment .
* Provide the standard device and the flow chart.
* According to the clients’ special requirement, offering the reasonable plan and free design helping to
select the equipment.
* Welcome to visit our factory.
(2)Services during the sales:
* Inspect the machine before leaving the factory.
* Oversea install and debug the equipment.
* Train the first-line operator.
(3)After sale services:
* 24 hours online service.
* Provide the VIDEO with Install and debug the equipment.
* Provide technical exchanging.
