Specifications
hydraulic press1.Used to prepress wood-based panel
2.High quality,excellent in function
3.Easy to operate
1. hydraulic press application
The machine is applied for modern fashion board,plyboard,flak-board,laminating board.woodbased panel board,furniure manufacture,solid board furniture,speaker box,plastic and wooden mould etc.
2.Technical specification:
| model | MYJ50T | MYJ80T | MYJ100T |
| Name of machine | Single-50Tpress | Cold single-80T press | Cold single-100T press |
| Size of worktable (mm) | 1250x2500 | 1250x2500 | 1250x2500 |
| Nominal pressure | 500KN (50T) | 800KN (80T) | 1000KN(100T) |
| Max. Platen Prening | 1050mm | 1050mm | 1050mm |
| Hydraulic pump power | 5.5 kw | 7.5 kw | 7.5 kw |
| Dimensions of macgune | 2960x1250x2950 | 2960x1250x2950 | 2960x1250x2950 |
| Circulate the way | auto | auto | auto |
3.Pictures
4. Features
1) Easy to operate, reasonable design, stable performance
2) Fast and efficient pressing.
3) Emergency safety braking.
4) Trip limited device.
5) Automatic compression and unloading pressure function
6) Work-table height convenient for human body.
5. Other Cold Press
(1) Pre-sale services:
* Provide the free consultation of the equipment .
* Provide the standard device and the flow chart.
* According to the clients’ special requirement, offering the reasonable plan and free design helping to
select the equipment.
* Welcome to visit our factory.
(2)Services during the sales:
* Inspect the machine before leaving the factory.
* Oversea install and debug the equipment.
* Train the first-line operator.
(3)After sale services:
* 24 hours online service.
* Provide the VIDEO with Install and debug the equipment.
* Provide technical exchanging.
Any doubts, let's talk then.
