Full Automatic Bearing Assembly Machine

Name: Full Automatic Bearing Assembly Machine
Brand: Huiguang
SKU: 125105035

Full Automatic Bearing Assembly Machine thumbnail-1

Full Automatic Bearing Assembly Machine photo-1

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Place of Origin:

Jiangsu, China

Brand Name:

Huiguang

Model Number:

BCJL02N

Contact Supplier Request Quote Chat Now

Wuxi Huiguang Precision Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Jiangsu, China

Brand Name Huiguang

Model Number BCJL02N

Condition New

After-sales Service Provided Engineers available to service machinery overseas

Specifications

Standard modular design for easy maintenance.
Proprietary imaging tech for inspection.
Manufacturing, customizable.

Product Description

BCJL02N Full Automatic Bearing Assembly Machine

These machines can mainly complete following working procedures: auto feeding or fed by prior step → ball collection & separation → lack of ball inspection → lack of ball products NG → placing cages and aligning position → lack of rivet inspection before riveting → riveting → rivet height inspection after riveting → discharge.

Product Advantages

Designed for the auto assembly of nylon cages.
Torque motor is used for rotary ball collection.
Ball separation and collection is flexible to minimize injuries to steel balls.
Unique dual-rod cage feeding structure and linkage mechanical pawl structure for cage picking.
Mature technologies are used in assembling nylon cages, including feeding with vibration disk, position correction with stepper motor, pressing with air cylinder.
All parameters such as number of steel balls, status of cages and sizes after riveting will be detected.
The standard modular structure design makes tooling changing and maintenance more convenient, and the performance more stable.
Security mechanism (national standard or European standard) can be customized based on requirements.

Technical parameters:

Applied nominal OD	D19-28
Efficiency	≈2.8s/piece
Lack of ball inspection	Optical fiber sensor inspection
Riveting mode	Air cylinder
Riveting inspection	By altitude difference
Dimension (mm)	1400 L * 800W * 1800H
Cylinder & Solenoid valve	AirTAC, SMC, Pneulead optional, or on request
PLC	OMRON, SIEMENS optional, or on request
Touch screen	Xinje, SIEMENS optional, or on request
Optical fiber+Amplifier	SUNX / KEYENCE, or on request
Stepper motor / Servo motor	YAKO, Mitsubishi optional, or on request
