4" super thin cut off wheel for steel(T41)
- 1500000 Piece / Pieces per Month
- Shanghai Qingdao Ningbo
- T/T Credit Card
Product Details
Place of Origin: | Henan, China | Brand Name: | PER CUT | Model Number: | T41 105x1.2x16mm |
Type: | Abrasive Disc | Size: | 105x1.2x16mm, 41/7x3/64x5/8inch |
Product Description
Specifications
1.First grade abrasives2.Two nets provide safe
3.Good tensile strength and high efficiency
4.excellent cutting performance
Description
1, High tensile strength fibreglass meshes, strong resin bond.
2, Advanced producting equipments and automatic production line.
3, Our products are very popular in South Asia, Southeast Asia, Africa etc.
4, Have ISO9001:2000 certificate and welcome OEM.
Application
Suitable for stainless steel and metal.
Safety Instructions
1, Wear protective goggles, ear protectors, dust respirators and gloves.
2, Don’t exceed maximum R.P.M.
3, Can’t be used to side grinding.
4, Pay attention to safety Instructions.
Hot Sale Products Technical Datas
Dimension | Dimension | Speed | Speed | G.Weight | Dimension | Packing pcs/carton |
105x1.2x16 | 41/7x3/64x5/8 | 14500 | 80 | 20 | 330x250x230 | 800 |
125x1.2x22.2 | 5x3/64x7/8 | 12200 | 80 | 22 | 410x280x185 | 600 |
100x3.0x16 | 4x1/8x5/8 | 15200 | 80 | 24 | 440x230x205 | 400 |
125x3.0x22.2 | 5x1/8x7/8 | 12200 | 80 | 28 | 410x280x205 | 300 |
180x3.0x22.2 | 7x1/8x7/8 | 8500 | 80 | 20 | 390x390x110 | 100 |
230x3.0x22.2 | 9x1/8x7/8 | 6600 | 80 | 16 | 490x250x115 | 50 |
300x3.0x25.4 | 12x1/8x1 | 5100 | 80 | 13 | 310x90x310 | 25 |
350x3.0x25.4 | 14x1/8x1 | 4400 | 80 | 18 | 360x90x360 | 25 |
400x3.0x25.4 | 16x1/8x1 | 3800 | 80 | 24 | 410x90x410 | 25 |
The cutting wheels producing process
part1. The materials
white aluminium oxide
brown aluminium oxide
silicon carbide
single crystal aluminium oxide
liquid phenolic resin
reinforced nets
Part2. Producing
Part3 Testing
Part4 Packing
We are always trying our best to satisfy your requirements and constantly pursuing excellent quality, reasonable price and incomparable service for you our kind customers.
Contact Us
- Henan Kaifeng City Yuguang Abrasives Factory
- Contact nameJerry Nai
- Phone86-371-24971303
- AddressSouth of the county Hanzhuang Tongxu Kaifeng,Henan
