Help CenterPOS 58mm Receipt Thermal Printer
Related Products
Specifications
58mm POS thermal Printer1) Paper width :80mm
2) With Auto Cutter
3) Serial,Parallel,USB ,Internet interface for optioanl
Specifications:
58mm POS thermal Printer
1) Print method: thermal line printing
2) Print speed: 230mm/sec
3) Paper width: 79.5±5mm
4) Print columns: 576 dots/line
5) Supports NV image download
6) Dot density: 203dpi (8 dots/mm)
7) Print character: ANK character
Font A: 12 x 24 dots
Font B: 9 x 17 dots
Simplified / traditional Chinese / Japanese / Korean: 24 x 24 dots
8) Language: English / French / German / Danish / Spanish / Japanese / Korean
9) Interface: parallel / RS232C / USB / wireless / Ethernet...etc.
10) Cutter: full or partial cut
11) Reliability print: 100km
12) Power Supply: DC 24V
13) Cash drawer: DC 12 - 24V / 1A
14) Temperature: 0 - 50oC
15) Paper thickness: 0.06 - 0.08mm
16) Dampness: 10 - 80%
17) Barcode mode: UPC-A / UC-E / JAN13 (EAN13) / JAN8 (EAN8) / code 39 / ITF / coda bar / code 93 / code 128
18) Drivers: Windows 9x / ME / 2000 / NT / XP, compatible with Epson and Samsung
19) Print command: compatible with ESC / POS
20) External dimensions (W x D x H): 114 x 185 x 90mm
Features:
1) Command protocol is based on ESC/POS standard
2) Low-noise thermal printing
3) Various layouts are possible by using page mode
4) Characters can be scaled up to 64 times as large as standard size
5) Repeated operation and copy printing are possible
6) Character font size (12 x 24 / 9 x 17 / 24 x 24 font as optional)
7) Easy paper-roll installation
8) Easy paper jam clearance
9) Easy maintenance for head cleaning
10) Built-in interface provides control capability for cash drawer
11) Color: grey and white
