G041 CM120SV Flysight FPV Mini CameraUltra Small HD FPV Helicopter Airplane Fast Action Camera System

Specifications

Flysight CM120SV
CCTV cameras can be used directly with a standard TV/VCR or RCA video monitor

Flysight  CM120SV  Flysight FPV Mini CameraUltra Small HD FPV Helicopter Airplane Fast Action Camera System



Product Description:

1.Features

1).0.008Lux 520TVL Mini CCTV Camera 90degree view angle
2).It’s an ultra small high definition CCTV camera with excellent night vision.
3).Size is 11.5 x 11.5 x 22.5mm  only, Weight is 1g! Very easy to install and conceal.
4).Minimum illumination is 0.008lux, which can view clearly in almost complete darkness.
5).90degree wide view angle provides broad surveillance field.

6).Full TV system. Applicable worldwide.

2.Specifications

DC3.3-6V 70mA Ultra Light and Mini FPV Camera:
Sensor	1/3CMOS
System	NTSC:656×492 PAL:768×576
Horizontal resolution	520TVL
Night vision	0.008Lux/F1.2
Lens & View Angle	0.5mm F2.0/ 55 °
Dimensions(LXWXH)	11.5 x 11.5 x 22.5mm
Power Supply	DC4-24V  70mA
Video Out	1.0V p-p/75ohm

3.Our Product Advantages:

Compatible Fatshark FPV Tx Transmitter

1. We promise not to do the domestic market, avoiding cross sales.

2. Original products for our own brand Flysight, quality is warranty.

3. We aim to provide customers high quality products and services.

4. Flysight hot  selling product models: TX58025,TX5802,TX5804,TX5812,TX5820,RC305,RC306.,RC801 etc.

5. OEM orders are welcome!

4. Usage

1) CCTV cameras can be used directly with a standard TV/VCR or RCA video monitor;
2) To view more than one CCTV camera on your TV/VCR you will need a quad or multiplexer;
3) To view on your computer or laptop you will need a DVR card or USB;
4) A standalone system that records is a standalone DVR;
5) CCTV wired cameras can add a 5.8GHz wireless transmitter module,then it can work with wireless receivers.

Product Image

CM120SV

Trade Terms

♦ Payment: T/T in advance (Western Union or PAYPAL are welcomed)

♦ Production lead time  500PCS: 5-7days, 500~1000PCS:10-15days, above 5000PCS 15-20days.

♦ Sample can be delivered in 3days

♦ Shipping freight are quoted under your requests

♦ Shipping port: Shenzhen, Mainland China

♦ Discounts are offered based on order quantities

♦ MOQ:10PCS

Our services

1. Your inquiry related to our products or prices will be replied in 24hrs.

2. Well-trained and experienced staffs to answer all your enquires in fluent English.

3. OEM&ODM, any your customized lightings we can help you to design and put into product.

4. Distributor ship are offered for your unique design and some our current models.

5. Protection of your sales area, ideas of design and all your private information.

6. We offer 1 year warranty of free repair or replace for all our products. If the goods have quality problem, we will replace within 3 months. In this case, we will have the faulty goods returned at first, and then we send the new ones to you with your next order.

Step1     Sending inquiry on site / email.

 (show us the item & quantity which you want to order).

Step2     We calculate price and confirm order with you.

Step3     You choose a payment method and arrange payment to us.

Step4     Send a payment receipt to us. together with your delivery address,zip code,

phone number,contact name .

Step5     We send items to you within a week after we received your payment.A tracking number will be email to you once it available.

Step6      You sign for parcel.Send feedback to us when you have time.
