G397 520tvl Mini Fpv Camera With 200mW Transmitter Module for rc Monster Truck

G397 520tvl Mini Fpv Camera With 200mW Transmitter Module for rc Monster Truck thumbnail-1
G397 520tvl Mini Fpv Camera With 200mW Transmitter Module for rc Monster Truck photo-1
US$ 1 - 47 MOQ: 10 Sets
Key Specifications
Get Latest Price
Material:
Other, PCB Board
Radio Control Style:
RC Hobby
Place of Origin:
Guangdong, China
Contact Supplier Request Quote Chat Now
Shenzhen Aoweishi Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Material Other, PCB Board
Radio Control Style RC Hobby
Place of Origin Guangdong, China
Brand Name flysight
Model Number CM100T

Specifications

Flysight CM100T FPV Mini Camera Transmitter CM100T
1. Mini
2. Lightest
3. 200mw 5.8Ghz
4. camera tx kit

 FPV Mini Camera And 200mw Transmitter Module Kit CM100T Flysight



G397 520tvl mini fpv camera with 200mW transmitter module for rc monster truck







Product Description

1.Features



This is kit comes with a micro FPV camera with a tiny 200mW 5.8Ghz Transmitter.  The entire kit (with camera/ transmitter) and wires weighs just 6g making this the ideal FPV camera TX combo if you don't have any spare weight on your FPV platform.  Its best to power this setput with a 1S lipo battery.





Dont think that due to the small size of this FPV camera that you are sacrificing quality.  The micro FPV camera features 520TVL (768x576) resolution with 0.008lux/F1.2 which gives it great low light performance.  Further more you receive a daytime and a nighttime lens with the camera.  The expected range for this 200mW FPV transmitter is around 750m, which is less than the larger FPV systems that we sell, but this is mainly due to the antenna.  You can always upgrade the antenna with one of our circular polarized antennas if you solder on a SMA or RP-SMA adapter (which we also sell).



2.Specifications

Ultra Light and Mini FPV Camera:

Sensor

1/3 CMOS

System

NTSC:656×492   PAL:768×576

Horizontal resolution

520TVL

Night vision

0.008Lux/F1.2

Lens & View Angle

0.5mm F2.0 / 55 °

Dimensions(LXWXH)

9.5 x 9.5 x 12mm (smallest)

Power Supply

DC3.3-6V 70mA

Video Out

1.0V p-p/75ohm

5.8G 200mW Wireless transmitter:

transmitter frequency

5725-5865MHz; 8 channels

transmitting power

23dBm /200mW

transmitting distance

>2000 metres

frequency control

built-in frequency and phase lock loop

AV input

analog AV signal input

power supply voltage

3.3V(don't use 5V)

supply current

320mA

dimension

19*19*3mm



Mini FPV Camera Specification:

  • Ultra light mini FPV camera
  • Sensor - 1/3 CMOS
  • System NTSC:656x493 PAL:768x576
  • Horizontal Resolution 520TVL
  • Excellent low light performance - 0.008Lux / F1.2
  • Lens and View Angle - 0.5mm F2.0 / 55°
  • Camera dimensions 9.5 x 9,5 x 12mm
  • Power supply: DC3.3-6V 70mA
  • Video Output: 1.0V p-p / 75ohm


Mini 5.8Ghz transmitter specifications:

  • Transmitter frequency:5725-5865MHz;  8 channels
  • Transmitting power:23dBm /200mW                                                 Frequency control: built-in frequency and phase lock loop
  • AV input:analog AV signal input
  • Power supply voltage: DC 3.3V (don't use 5V long time)                  supply current:320mA

  • dimension:19 x 19 x 3mm


  • FPV Kit contents:

    • 1x Micro FPV Camera
    • 1x Daylight Lens
    • 1x Night time Lens
    • 1x Micro 5.8Ghz Transmitter with built in antenna
    • 1x RCA Video Cable set


How do I Change the the FPV transmitter channels?



The channels can be selected or changed on your transmitter module by soldering jumpers between the Channel 1, 2, and 3 pins and ground as described below.

  • Ch1 pin + Ch2 pin + Ch3 pin connect to ground (Channel 1 - 5.705 gHz)
  • Ch2 pin + Ch3 pin connect to ground (Channel 2 - 5.685 gHz)
  • Ch1 pin + Ch3 pin connect to ground (Channel 3 - 5.665 gHz)
  • Ch1 pin + Ch2 pin connect to ground (Channel 5 - 5.885 gHz)
  • Ch3 pin connect to ground (Channel 4 - 5.645 gHz)
  • Ch2 pin connect to ground (Channel 6 - 5.905 gHz)
  • Ch1 pin connect to ground (Channel 7 - 5.925 gHz)
  • DEFAULT - no connect to ground (Channel 8 - 5.945 gHz)



3.Our Product Advantages:

Compatible Fatshark FPV Tx Transmitter



1. We promise not to do the domestic market, avoiding cross sales.



2. Original products for our own brand Flysight, quality is warranty.



3. We aim to provide customers high quality products and services.



4.  Flysight hot  selling product models: TX58CE,TX5802,TX5804,TX5812,TX5820 V2,RC305,RC306.,RC801 etc.



5. OEM orders are welcome!





4. Usage


1) So light,proper for small toy plane



2) Easy to hide for spy purpose



3) Long Open distance









Product Image

CM100T

G397 520tvl mini fpv camera with 200mW transmitter module for rc monster truckG397 520tvl mini fpv camera with 200mW transmitter module for rc monster truckG397 520tvl mini fpv camera with 200mW transmitter module for rc monster truckG397 520tvl mini fpv camera with 200mW transmitter module for rc monster truckG397 520tvl mini fpv camera with 200mW transmitter module for rc monster truck









Trade Terms



♦ Payment: T/T in advance (Western Union or PAYPAL are welcomed)



♦ Production lead time  500PCS: 5-7days, 500~1000PCS:10-15days, above 5000PCS 15-20days.



♦ Sample can be delivered in 3days



♦ Shipping freight are quoted under your requests



♦ Shipping port: Shenzhen, Mainland China



♦ Discounts are offered based on order quantities



♦ MOQ:10PCS







Our Services



1. Your inquiry related to our products or prices will be replied in 24hrs.



2. Well-trained and experienced staffs to answer all your enquires in fluent English.



3. OEM&ODM, any your customized lightings we can help you to design and put into product.



4. Distributor ship are offered for your unique design and some our current models.



5. Protection of your sales area, ideas of design and all your private information.



6. We offer 1 year warranty of free repair or replace for all our products. If the goods have quality problem, we will replace within 3 months. In this case, we will have the faulty goods returned at first, and then we send the new ones to you with your next order.






How To Order



Step1     Sending inquiry on site / email.



 (show us the item & quantity which you want to order).



Step2     We calculate price and confirm order with you.



Step3     You choose a payment method and arrange payment to us.



Step4     Send a payment receipt to us. together with your delivery address,zip code,phone number,contact name .



Step5     We send items to you within a week after we received your payment.A tracking number will be email to you once it available.



Step6      You sign for parcel.Send feedback to us when you have time.
