C569 5.8g wireess transmitter 200mw module with night vision camera for Small RC airplane

Specifications

SENSOR :1/3 CMOS
SYSTEM: NTSC: 656*492 PAL:768*576
HORIZONTAL RESOLUTION: 520TVL

C569 5.8g wireess transmitter 200mw module with night vision                        camera for Small RC airplane



Features of combination of Micro Camera and 5.8G 200mW Transmitter:

Super light and super mini camera

9.5X9.5X12mm

4Gram only of the combination of FPV Camera and 5.8G 200mW Transmitter

High definition micro CCTV camera,520TVL

0.008lux,can view clearly in almost complete darkness

Double lens-day&night offered





Specifications of combination of FPV Camera and 5.8G 200mW Transmitter:



Ultra Light and Mini FPV Camera

SENSOR :1/3 CMOS

SYSTEM:   NTSC:656×492   PAL:768×576

HORIZONTAL RESOLUTION:520TVL

Exellent night vision of 0.008Lux/F1.2

LENS & VIEW ANGLE :0.5mm F2.0 / 55 °

Dimensions(LXWXH):9.5 x 9.5 x 12mm (smallest)

POWER SUPPLY: DC3.3-6V 70mA

VIDEO OUT:1.0V p-p/75ohm



5.8G 200mW Wireless transmitter:

Transmitter frequency: 5645-5945MHz;8CH

Transmitting Power: 200mW/23dBm

Transmitting distance: >2000m(open area)

Frequency control: built-in frequency and phase lock loop

ANT connector: SMA(inside the needle)

AV input: analog AV signal input

power supply: 6-16 volts

Current supply: 130mA

Size: 57*27.2*12mm

Net weight: 16g(no cable and antenna)



Note: antennas must be attached before powering on.



Usage:

So light, proper for small toy plane

Easy to hide for spy purpose

Long Open distance



1. Your inquiry will be replied within 24hrs except weekend.
2. Well-trained and experienced staffs can answer all of your questions
3. OEM&ODM, any your customized requirement within our ability can be come true.
4. Agency is welcomed.
5. Protection of your sales area, ideas of design and all your private information



1. FOB Price:
At present, we only offer EXW price to all our customers for small orders, but for a large order, we will ship by container, we will offer you price on FOB Shenzhen.



2. Payment term:
At present, we only accept paying by T/T , Western Union and Paypal.



3. Minimum Order Quantity(MOQ):
No matter how many do you want, we can also offer you it. Usually, our M. O. Q is 50 PCS/kits for each item.



4. Price list:
Welcome to visit our website and choose what you like, then send us your enquiry letter or chat with us on Trade Manager. Price of the items you selected will be sent to you in our reply email. Our price depends on your quantity. We are manufacturer, so we promise to offer you the best price.



5. Delivery time and OEM Order
If the products are NOT made based on your Trade Mark, we can send the goods to you with three work days after we receive the payment.
There is no problem for us to offer customized requirement, such as package you designed, antenna connector, output voltage.The delivery would be about 35 days due to printing the package you designed from the very beginning, but it would only need about 20 days for the repeated order.



6. How to get the sample:
So sorry to say that we don't offer free samples. When you confirm the model that you need, PI will be send to you,freight charge included. Sample will be send within 3 workdays after getting the payment.



7. Shipping:
DHL is better if the order is not large. For large order, we suggest air freight which costs you not so much. The shipping costs depends on the total weight of your products.



8. Warranty:
1 year warranty of free repair or replace for our products. Within 3 months, if some quality problems, you can replace it with a good one. But faulty goods should be returned before we send you a new one.
