C81 rc Helicopter Camera Video With Servo Pan-Tilt Bracket

C81 rc Helicopter Camera Video With Servo Pan-Tilt Bracket photo-1
US$ 1 - 58 MOQ: 1 Unit
Key Specifications
Get Latest Price
Brand Name:
Flysight
Model Number:
CM210
High Definition Support:
Other, NTSC:656*492 PAL:768*576
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Brand Name Flysight
Model Number CM210
High Definition Support Other, NTSC:656*492 PAL:768*576
Color Black
Place of Origin Guangdong, China

C81 rc helicopter camera video with Servo Pan-Tilt bracket



Features:



Camera:




1/3" 540TVL SONY CCD
0.01 LUX minimum illumination
2.1mm / 2.8mm / 3.6mm lens optional, by default we will ship the 3.6mm lens
Built-in MIC
3pin FPV transmitter cable (without audio)
Dimension: 30mm X 30mm X 10mm
Net weight 14g
DC 9-12V power input
1.0Vp-p/75ohm analog video output



PT:
Horizontal rotation range: 180 deg.
Horizontal rotation speed: 100 deg./s
Tilt rotation range: 130 deg.
Tilt rotation speed: 100 deg./s
Dimension: 32mm X 28mm X 65mm
Net weight: 42g



Note
The model of the R/C remote controller supported by this FPV systems: FUTABA FF-7, FF-8, FF-9, T9Z, T12MZ and T14MZ.
The power adapter is not included.

 C81 rc helicopter camera video with Servo Pan-Tilt bracketC81 rc helicopter camera video with Servo Pan-Tilt bracket
