5.8Ghz Vtx Circular Polarized Antenna Set RP-SMA Connector825564880

Specifications

1. Improved signal reception on all bands ;
2. Brought 5.8Ghz video from one of the least practical systems

Description:



1.//  Circular Polarization is one of the biggest step forward in the progression of the FPV experience of the last few years. It has improved signal reception on all bands and brought 5.8Ghz video from one of the least practical systems to now one of the best.



2.// This is a 5.8Ghz Cloverleaf antenna for your transmitter.  A plastic enclosure is included to stop the antenna from being bent or damaged.  The connection on this antenna is a RPSMA type connector.  We sell this antenna with both SMA and RP-SMA connectors, so fi you require a specif one please have a look at the other variants of this antenna.



3.// A cloverlead antenna has 3 distinct lobes on it.  Is is usualy used to connect to your transmitter unit that is onboard your multicopter or aircraft.   This is an omni-directional antenna so you might have some signal loss when you are flying directly above the reciever as this antenna does not rediate directly below or above the antenna axis.  However overall the cloverleaf antenna is the best type to use for your transmitter.





Cloverleaf Antenna specifications:

• Gain: 5dBi
• Antenna connector: RPSMA Plug
• Standing wave ratio(SWR): <1.5
• Length: 8cm
• Weight: 12.5g



Standard gift packaging box:
