Specifications
Audio Video RC306 Receiver1.With channel changing button
2.Dispaly channel number with LED
Audio Video RC306 Receiver
C518 Flysight FPV 5.8GHz 32CH Wireless Audio Video RC306 Receiver for FPV TX Transmitter Kit
RC306 Specification
- Receiving frequency:5665-5945MHz;7CH/32CH
- Receiving sensitivity:-90dBm
- Frequency control:built-in frequency and phase lock loop
- Double lines AV output:analog AV signal output
- Antenna connector:SMA(Inside the needle)
- Power supply voltage: 6-16V
- Supply current: 60mhA
- Dimension: 55x40x15mm (aluminium alloy caase)
- Note:the av cable uses 3.5mm plug on the receiver RC306
Receiver Frequency
CH1: 5705 CH2:5685
CH3:5665 CH4:5645
CH5:5885 CH6:5905
CH7:5925 CH8:5945
Inside the Package
1x RC306 mini Receiver
1x Duck antenna for Receiver
1x power cable
1x RCA cable connector set for video output
1. Your inquiry will be replied within 24hrs except weekend.
2. Well-trained and experienced staffs can answer all of your questions
3. OEM&ODM, any your customized requirement within our ability can be come true.
4. Agency is welcomed.
5. Protection of your sales area, ideas of design and all your private information
-Your 5.8G new version Rx TX are every good, thank you! I will place the next order very soon--- Walid(from Texas, USA)
- Your products give me a surprise, you're the best that i've come across. --- Chris(from United Kingdom)
- Thank you for your help and for the photos, are very explicit,you will get new order sooner--Jose from Mexico
1. FOB Price:
At present, we only offer EXW price to all our customers for small orders, but for a large order, we will ship by container, we will offer you price on FOB Shenzhen.
2. Payment term:
At present, we only accept paying by T/T , Western Union and Paypal.
3. Minimum Order Quantity(MOQ):
No matter how many do you want, we can also offer you it. Usually, our M. O. Q is 50 PCS/kits for each item.
4. Price list:
Welcome to visit our website and choose what you like, then send us your enquiry letter or chat with us on Trade Manager. Price of the items you selected will be sent to you in our reply email. Our price depends on your quantity. We are manufacturer, so we promise to offer you the best price.
5. Delivery time and OEM Order
If the products are NOT made based on your Trade Mark, we can send the goods to you with three work days after we receive the payment.
There is no problem for us to offer customized requirement, such as package you designed, antenna connector, output voltage.The delivery would be about 35 days due to printing the package you designed from the very beginning, but it would only need about 20 days for the repeated order.
6. How to get the sample:
So sorry to say that we don't offer free samples. When you confirm the model that you need, PI will be send to you,freight charge included. Sample will be send within 3 workdays after getting the payment.
7. Shipping:
DHL is better if the order is not large. For large order, we suggest air freight which costs you not so much. The shipping costs depends on the total weight of your products.
8. Warranty:
1 year warranty of free repair or replace for our products. Within 3 months, if some quality problems, you can replace it with a good one. But faulty goods should be returned before we send you a new one.
