G1529 DV05S V2 5.8GHz 5 Inch 32CH FPV DVR LCD Monitor With Easy Folding Sun Hood

G1529 DV05S V2 5.8GHz 5 Inch 32CH FPV DVR LCD Monitor With Easy Folding Sun Hood photo-1
G1529 DV05S V2 5.8GHz 5 Inch 32CH FPV DVR LCD Monitor With Easy Folding Sun Hood photo-2
G1529 DV05S V2 5.8GHz 5 Inch 32CH FPV DVR LCD Monitor With Easy Folding Sun Hood photo-3
G1529 DV05S V2 5.8GHz 5 Inch 32CH FPV DVR LCD Monitor With Easy Folding Sun Hood photo-4
G1529 DV05S V2 5.8GHz 5 Inch 32CH FPV DVR LCD Monitor With Easy Folding Sun Hood photo-5
G1529 DV05S V2 5.8GHz 5 Inch 32CH FPV DVR LCD Monitor With Easy Folding Sun Hood photo-6
US$ 1 - 112 MOQ: 10 Sets
Key Specifications
Get Latest Price
Type:
Helicopter
Power:
Battery
Material:
Other, PCB Board
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen China
Delivery Detail:
Delivery time depends on order quantity.
Type Helicopter
Power Battery
Material Other, PCB Board
Radio Control Style RC Hobby
Place of Origin Guangdong, China
Brand Name flysight
Model Number DV05S V2







  DV05S V2  Wireless 5inch 1.2G/2.4G/ 5.8G portable FPV DVR with sunshade for DJI/Boscam drone (32chs , 3200mah battery)





G1529 DV05S V2 5.8GHz 5 inch 32CH FPV DVR LCD monitor with easy folding sun hood







Product Description

1.Features

It supports both wireless and wired cameras. Frequency can be 1.2Ghz, 2.4Ghz, 5.8Ghz. Not only this, it adds new function of photo, loop recording, power saving (auto shutdown, auto off-screen), etc. This DVR is the ideal choice for security & protection, evidence & investigation, like police, household, sports, automotive industry, shops, etc...At the same time, with its stylish and high-end appearance, it also becomes the fashion choice of leisure goods.







2.Specifications

Items

             Value

Wireless Receiving

5.8GHz   32 channels

A1:5.740GHz;A2:5.760GHz;

A3:5.780GHz;A4:5.800GHz

A5:5.820GHz;A6:5.840GHz;

A7:5.860GHz;A8:SPI

B1:5.725GHz;B2:5.745GHz;

B3:5.765GHz;B4:5.785GHz

B5:5.805GHz;B6:5.825GHz;

B7:5.845GHz;B8:5.865GHz

C1:5.733GHz;C2:5.752GHz;

C3:5.771GHz;C4:5.790GHz

C5:5.809GHz;C6:5.828GHz;

C7:5.847GHz;C8:5.866GHz

D1:5.705GHz;D2:5.685GHz;

D3:5.665GHz;D4:5.645GHz

D5:5.885GHz;D6:5.905GHz;

D7:5.925GHz;D8:5.945GHz

2.4GHz–8 channels

A1: 2414MHz;A2:2432MHz;

A3: 2450MHz;A4:2468MHz.

A5:2490MHz;A6:2510MHz;

A7: 2390MHz;A8:2370MHz

1.2GHz–8 channels

A1:1080 MHz;A2:1120MHz;

A3:1160MHz;A4:1200MHz

A5:1010 MHz;A6: 1040MHz;

A7:1240MHz;A8:1280MHz

1.2G-B–4 channels

A1:1258MHz;A2:1280MHz;

A3:1320MHz;A4:1360MHz

Within 5.8G-A

   8 channels

A1: 5865MHz;A2: 5845MHz;

A3: 5825MHz;A4: 5805MHz.

A5: 5785MHz;A6: 5765MHz;

A7: 5745MHz;A8: 5725MHz

Beyond 5.8G-B

8 channels

A1: 5705MHz;A2: 5685MHz;

A3: 5665MHz;A4: 5645MHz.

A5: 5885MHz;A6: 5905MHz;

A7: 5925MHz;A8: 5945MHz

Within 5.8G-C

  8 channels

A1: 5733MHz;A2: 5752MHz;

A3: 5771MHz;A4: 5790MHz.

A5: 5809MHz;A6: 5828MHz;

A7: 5847MHz;A8: 5866MHz

Within 5.8G-D

7channels for FPV

A1: 5740MHz;A2: 5760MHz;

A3: 5780MHz;A4: 5800MHz.

A5: 5820MHz;A6: 5840MHz;

A7: 5860MHz;A8: SPI

Beyond 5.8G-E

7 channels for FPV

A1: 5705MHz;A2: 5685MHz;

A3: 5665MHz;A4: 5645MHz.

A5: 5885MHz;A6: 5905MHz;

A7: 5925MHz;A8: SPI

Sensitivity

-88dB

AV IN

TV system

NTSC / PAL

Output voltage

3.6-4.2 V

AV OUT

TV system

NTSC / PAL

HD 5-inch LCD screen

Active area

108mm(W)  X  64.8mm(H)

Resolution

800 X 480 Pixel

Luminance for LCD

300 cd/m2

Video

Resolution

720*576 / 720*480

Video compress

MPEG-AVI    30fps

Play format

MPEG-AVI

Audio

Frequency

20HZ-20KHz stereo

Earphone Output

Left: 20MW+ right 20mW [16O](suit to largest volume)

Speaker

1W


Format

JPG/JPEG

Storage

External SD card

TF card  1GB-32GB(optional)

32GB recording time

10-32 hours

1GB photos

15625pcs

Operating system

PC

Windows & Mac OS

Port

USB 2.0

Language

Multiple

Power

Voltage

DC 5V

Current(receiving mode)

660MA

Current( recording mode)

680MA

Current(recording with off-screen mode)

340MA

AC adapter

DC 5V  2A

Built-in battery

Li-battery 3200Mah

Standby time

Wireless record

≥9.5 hours(off-screen);  ≥5hours(on-screen)

Wired record

≥12 hours(off-screen);  ≥6hours(on-screen) *LED camera not included.

size:

without sunshield

131mm x 90.5mm x 18mm

size

with sunshield

131mm x 90.5mm x 28mm

Weight

without sunshield

215 g

Weight

with sunshield

260 g









3.Our Product Advantages:



1).32chs 5.8Ghz receiver with -88db.
Frequency mode: 1.2Ghz, 2.4Ghz, 5.8Ghz, it won't blues creen when signal weak. Mini size and portable recorder with fashionable & new design;One-press open sunshade can help you see clear under sunshine outdoor .



2)5-inch HD screen (800X480pix), which provides clear and smooth image;



3).Built-in 3200mAh high capacity Li-battery provides super long recording time up to 9.5 hours;



4).TF card Supports storage up to 32GB , which records up to 32 hours;
Folding hidden external antenna assures excellent wireless receiving;



5).Supports AV IN function: Receiving signal from wired cameras;



6).Supports AV OUT function: Connecting to big screen monitor.



7).Photo function: It can take, review & store pictures;



8).Supports intelligent motion detect video recording;
Overwrite: It supports loop recording, which can automatically overwrite when storage is full;
Seamless continuous record: No intermittent recording, it will not miss any detail and wonderfulness;



9).Support power-saving mode: Automatic shutdown, automatic off-screen;
Equipped with full set of mounting brackets, it can be hand-held, stand desktop, hanging on the wall, placed inside the car, different occasions.

It's of high compatibility, which supports almost all computer operating system, including MAC;



10).Supports multi-language,
