5.8GHz 5'' Wireless HD Mini Portable Wired PVR Screen Recorder
Introduction:
A new generation portable mini DVR PVR developed by our company.It supports both wireless and wired cameras. Not only this, it adds new function of photo, motion detect, loop recording, power saving (auto shutdown, auto off-screen), etc. This DVR PVR is the ideal choice for security & protection, evidence & investigation, like police, household, sports, automotive industry, shops, etc.. At the same time, with its stylish and high-end appearance, it also becomes the fashion choice of leisure goods.
Unique feature
1.Mini size and portable recorder with fashionable & new design;
2.5-inch super large HD screen (800X480pix), which provides clear and smooth image;
3.Built-in 3200mAh high capacity Li-battery provides super long recording time up to 9.5 hours;
4.Supports storage up to 32G TF card, which records up to 32 hours;
5.Supports 2.4GHz & 5.8GHz wireless frequency;
6.8 channels auto/manual switch;
7.Folding hidden external antenna assures excellent wireless receiving;
8.Supports AV IN function: receiving signal from wired cameras;
9.Photo function: it can take, review & store pictures;
10.Supports intelligent motion detect video recording;
11.Overwrite: It supports loop recording, which can automatically overwrite when storage is full;
12.Seamless continuous record:No intermittent recording, it will not miss any detail and wonderfulness;
13.Support power-saving mode: automatic shutdown, automatic off-screen;
14.Equipped with full set of mounting brackets, it can be hand-held, stand desktop, hanging on the wall, placed inside the car, different occasions;
15.It’s of high compatibility, which supports almost all computer operating system, including MAC;
16.Supports multi-language.
Specifications:
Wireless Receiving( Choose 1 group of frequency from 2.4G/within 5.8G/beyond 5.8G)
2.4GHz –8 channels CH1: 2414MHz; CH2: 2432MHz; CH3: 2450MHz; CH4: 2468MHz.CH5: 2490MHz; CH6: 2510MHz; CH7: 2390MHz; CH8: 2370MHz
Within 5.8G—8 channels CH1: 5865MHz; CH2: 5845MHz; CH3: 5825MHz; CH4: 5805MHz.CH5: 5785MHz; CH6: 5765MHz; CH7: 5745MHz; CH8: 5725MHz
Beyond 5.8G—8 channels CH1: 5705MHz; CH2: 5685MHz; CH3: 5665MHz; CH4: 5645MHz.CH5: 5885MHz; CH6: 5905MHz; CH7: 5925MHz; CH8: 5945MHz
Sensitivity: -92dB
Receiving distance: 100 meters
TV system: NTSC / PAL
Output voltage: 3.6-4.2 V
HD 5-inch LCD Screen:
Active area: 108mm(W) X 64.8mm(H)
Resolution: 800 X 480 Pixel
Luminance for LCM: 200 cd/M^2
Cape clear 5-inch LCD screen:
Active area: 118mm(W) X 62.8mm(H)
Resolution: 480 X 272 Pixel
Luminance for LCM): 300cd/M^2
Video Resolution: 720*576 / 640*480
Video compress: MPEG-AVI 30fps
Play format: MPEG-AVI
Audio Frequency: 20HZ-20KHz stereo
Earphone Output: Left: 20MW+ right 20mW [16O](suit to largest volume)
Speaker: 1W
Photo Format: JPG/JPEG
External SD card: TF card 1GB-32GB(optional)
32GB recording time 10-32 hours
1GB photos: 15625pcs
Operating system: PC Windows & Mac OS
Port: USB 2.0
Language Multiple
Power Voltage: DC 5V
Current(receiving mode): 660MA
Current( recording mode): 680MA
Current(recording with off-screen mode:) 340MA
AC adapter: DC 5V 2A
Built-in battery: Li-battery 3200mAh
Standby time:
Wireless record: ≥9.5 hours(off-screen); ≥5hours(on-screen)
Wired record: ≥12 hous(off-screen); ≥6hours(on-screen) *LED camera not included.
Size (L x W x H): 131mm x 86mm x 18mm
Weight(g): 205g
Package Content:
DVR X 1unit
User manual X 1 PC
Stereo earphone X 1unit
USB Cable X1 PC
AC adapter X1 unit
Back holder for installation X 1 pc
