131682 rc helicopter mini camera with wireless transmitter
for dji phantom quadcopter
This is kit comes with a mini fpv camera with a tiny 200mW 5.8Ghz wireless Transmitter for DJI phantom ,DJI quadcopter. The entire kit (with camera/ transmitter) and wires weighs just 6g making this the ideal FPV camera TX combo if you don't have any spare weight on your FPV platform. Its best to power this setput with a 1S lipo battery.
Dont think that due to the small size of this FPV camera that you are sacrificing quality. The micro FPV camera features 520TVL (768x576) resolution with 0.008lux/F1.2 which gives it great low light performance. Further more you receive a daytime and a nighttime lens with the camera. The expected range for this 200mW FPV transmitter is around 750m, which is less than the larger FPV systems that we sell, but this is mainly due to the antenna. You can always upgrade the antenna with one of our circular polarized antennas if you solder on a SMA or RP-SMA adapter (which we also sell).
Mini FPV Camera Specification:
- Ultra light mini FPV camera
- Sensor - 1/3 CMOS
- System NTSC:656x493 PAL:768x576
- Horizontal Resolution 520TVL
- Excellent low light performance - 0.008Lux / F1.2
- Lens and View Angle - 0.5mm F2.0 / 55°
- Camera dimensions 9.5 x 9,5 x 12mm
- Power supply: DC3.3-6V 70mA
- Video Output: 1.0V p-p / 75ohm
Mini 5.8Ghz transmitter specifications:
- Transmitter frequency:5725-5865MHz; 8 channels
- Transmitting power:23dBm /200mW
- Frequency control: built-in frequency and phase lock loop
- AV input:analog AV signal input
- Power supply voltage: DC 3.3V (don't use 5V long time)
- supply current:320mA
- dimension:19 x 19 x 3mm
FPV Kit contents:
- 1x Micro FPV Camera
- 1x Daylight Lens
- 1x Night time Lens
- 1x Micro 5.8Ghz Transmitter with built in antenna
- 1x RCA Video Cable set
How do I Change the the FPV transmitter channels?
The channels can be selected or changed on your transmitter module by soldering jumpers between the Channel 1, 2, and 3 pins and ground as described below.
- Ch1 pin + Ch2 pin + Ch3 pin connect to ground (Channel 1 - 5.705 gHz)
- Ch2 pin + Ch3 pin connect to ground (Channel 2 - 5.685 gHz)
- Ch1 pin + Ch3 pin connect to ground (Channel 3 - 5.665 gHz)
- Ch1 pin + Ch2 pin connect to ground (Channel 5 - 5.885 gHz)
- Ch3 pin connect to ground (Channel 4 - 5.645 gHz)
- Ch2 pin connect to ground (Channel 6 - 5.905 gHz)
- Ch1 pin connect to ground (Channel 7 - 5.925 gHz)
- DEFAULT - no connect to ground (Channel 8 - 5.945 gHz)
♦ I am especially happy with the micro fpv kit. Can you give me a price for that with quantity breaks? I would like to see what type of quantity I would need to but to get a competitive price for the monitor and 200mw as well. -- Dan from CA ,USA
♦100% love those micro FPV kit. I will be ordering more this week. ----Katy(from CA,USA)
♦ The CM100T work great ! -- Roy from Singapore
Our service:
1. Your inquiry related to our products or prices will be replied in 24hrs.
2. Well-trained and experienced staffs to answer all your enquires in fluent English
3. OEM&ODM, any your customized lightings we can help you to design and put into product.
4. Distributoership are offered for your unique design and some our current models
5. Protection of your sales area, ideas of design and all your private information
♦ Payment: T/T in advance (Western Union or PAYPAL are welcomed)
♦ Production lead time 500PCS: 5-7days, 500~1000PCS:10-15days, above 5000PCS 15-20days.
♦ Sample can be delivered in 3days
♦ Shipping freight are quoted under your requests
♦ Shipping port: Shenzhen, Mainland China
♦ Discounts are offered based on order quantities
♦ MOQ:50PCS
Mini FPV Camera with 5.8Ghz 200mW wireless transmitter Combo
Unique Feature: | |
This is kit comes with a micro FPV camera with a tiny 200mW 5.8Ghz wireless Transmitter for dji phantom dji quadcopter . The entire kit (with camera/ transmitter) and wires weighs just 6g making this the ideal FPV camera TX combo if you don' t have any spare weight on your FPV platform. Its best to power this setput with a 1S lipo battery : ) | |
Mini FPV camera Specifications: | |
Model |
CM100 1g very weightlight mini camera |
Style |
Ultra light mini FPV camera |
Sensor |
1/3CMOS |
System |
NTSC: 656x493 PAL: 768x576 |
Horizontal Resolution |
520TVL |
Excellent Low light performance |
0.008Lux/F1.2 |
Lens and View Angle |
0.5mm F2.0/55° |
Camera dimensions |
9.5x9.5x12mm |
Power Supply |
DC3.3-5V/70mA |
Video output |
1.0Vp-p/75ohm |
Mini 5.8Ghz Transmitter specifications: | |
Model |
M5802 wireless transmitter |
Transmitter Frequency |
5725-5865MHZ; 8Channel |
Transmitting Power |
23dBm/200mW |
Frequency Control |
Built-in Frequency and phase lock loop |
AV input |
Analog AV signal input |
Power Supply Voltage |
DC3.3V-5V(better not use 5V for long time) |
Supply current |
320mA |
Dimension(L*W*H) |
19x19x3mm |
Application:
RC airplane, Rc helicopter, dji phantom, dji quadcopter
